Price: | US $ 1/Piece |
---|---|
Trade Terms: | FOB |
Min Order: | 1/Piece |
Pay Type: | L/C,T/T,Paypal,Western Union |
Lema KW12-55 UL lever solder terminal subminiature micro switch
Operating speed | 0.1mm-1m/s | |
Operating frequency | Mechanical:60 times/min | |
Electrical:25 times/min | ||
Initial insulation resistance | 100MΩmin.(at 500VDC) | |
Initial contact resistance | 25MΩmax. | |
Dielectric strength | Between non-consecutive terminals | 1,000Vrms, 50/60Hz for 1 min |
Between non-current carrying metal parts and each terminal | 1,500Vrms, 50/60Hz for 1 min | |
Between ground and each terminal | 1,500Vrms, 50/60Hz for 1 min | |
Vibration resistance | 10-55Hz,1.5mm double amplitude | |
Shock resistance | Destruction | O.F.>0.5N:1000m/s2(Approx.100G)max. O.F.≤0.5N:400m/s2(Approx.40G)max. |
Malfunction | O.F.>0.5N:200m/s2(Approx.20G)max. O.F.≤0.5N:100m/s2(Approx.10G)max. | |
Operating life | Mechanical life | 1,000,000 operations min. |
Electrical life | 50,000 operations min. | |
Weight | Approx.1.6g (no lev |
Prod Model: | KW-1-28 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color: | Black, Green |
Terminal: | Quick Contect , or Straight PCB Terminals |
Size: | 19.8(10.6*6.35mm) |
Characteristics: | Long Mechanical Life , Electrical Life |
Application: | Electronic Products, Domestic Electric Appliances |
Certification: | CE,UL,CCC |
Dimension: | 59.5*30*19.5cm |
Minimum Quantity Request: | No |
