Product Specifications
| Prod Model: |
MX-A0001 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Resolution Of Loading: |
1/10,000fs |
| Type: |
Material Testing Machine |
| Weight: |
0-100Kg |
| Oil Cylinder Position: |
No |
| Power Source: |
AC 110V / AC 220V |
Product Description
Capacity of 250, 500, 1,000kgf, 3,000kg (500lbf, 1,000lbf, 2,000lbf, 6,000lbf) are designed to test a wide range of materials in tension, compression, flexure, shear and peel
The tester is PC-controlled with VFC motor for ideal and smooth control of speed from 5mm to 100mm/minute
The machine talk directly with a standard PC running a data analysis software package in English or Chinese, via a high speed RS232 in super high-speed binary modes
A huge assortment of specimen grips and fixtures are available, allowing the selection of an ideal grip for your application
Computer is required (prepared by customer)
Specifications:
| PC control and specified Universal material testing software via high-speed |
|
| PC closed-loop controls VFC motor and drives quality T-screw offers a wide range test speed |
|
| Test space (W x H): | 400 x 800mm |
| Loading measurement accuracy: | ±-0.5% (2%-100%FS), ±1% (1%-100%FS) |
| Resolution of loading: | 1/10,000fs |
| Displacement resolution and accuracy: | 0.1mm, ±1% of indicate ±value |
| Speed range and accuracy: | 50 - 300mm/minute, ±1% of set speed |
| Top and bottom over-run protection |
|
| Operating temperature range: | 0 to 38 degrees Celsius |
| Storage temperature range: | -10 to 45 degrees Celsius |
| Humidity range: | 10 to 90% RH non-condensing, Web bulb method |
| Power must be free of spikes and surges exceeding 10% of the nominal voltage |
|
| Dimensions (W × D × H) : | 700*900*1200mm |
Standards:
ASTM D76, ASTM D5034/5035, ASTM D2261/D434/D4964/5587/D3936, JIS L1093, GB/T 3923 1/2, GB/T 13772.1/2/3, GB 8687, FZ/T 20019/70006/70007/01085/01030
