Adopt the advanced process design.
High rigidity machine body, perfect protecting equipment and steady-going control system.
X, Y motors are driven by servo system, and principal axis takes frequency ports system.
Test the working state of all sensors and computer in real time.
Auto-stop system when the upper or bottom thread broke by infrared.
Auto lift needle and adjust the speed by computer.
Auto faults tips for servo motor system and transducer which is convenient to eliminate problems.
360 degree quilting and limitless multi-span and independent quilting.
Steady running, high speed, low noise, very thick material with pricise quilting.
Ringing notice when start machine.
Technical Parameter:
Max quilting width: 2485mm
Needle bar space: 50.8, 76.2, (2"+3")/76.2, 76.2, (3"+3")
Needle space: 24.5mm
X-axis movement: 410mm
Quilting thickness: 50mm
Stitch: 2-8
Output: 45-180m/hour
Needle type: #21-#24
Rolling speed: 600-900r/min
Rated voltage (AC): 380V 3phase 50Hz / 220V 3phase 60Hz
Power: 5KW
Machine size: L*W*H 4800*1600*2000mm
Weight: 4000kgs
