Computerized lock sitch multi needle garment machinery
FUNCTION
1. Adopt the advanced computer control project and mechanical quilting technology.
2. Saddling rack and Roller adopt the high efficient imported servo driving equipment.(Panasonic or otherwise)
3. The principal shaft adopts the transducer control device.
4. Convenient and efficient editing, simulating and tracking pattern function. And a lot of patterns can be chosen in computer in quilt machine
5. Unlimited and independent interval pattern sewing function, sewing in 360°direction.
6. Auto stop function when exceeding the max horizontal movement in right and left.
7. Continuous and jump quilt. No stopping between two changes.
8. Computer can auto test and adjust the speed; the speed of needle can reach 550 n/M, 2 -6 mm of needle stitch can be set
9. Auto needle raising and orientation stop system and auto stop function on the breaking of thread(can be choose)
10. The safety system is controlled by infrared built-in quilt machine
NEEDLE BAR ( Material imported from Germany, fabricated in factory)
DIMENSIONAL PATTERN ( Left and right shuttle quilt)
Technical Specification Of computer shuttle Quilt garment Machine |
Spec. Model | Over size (L*W*H) (mm) | Wight (KG) | Max. Quilt width (mm) | Max. Quilting thick-ness (mm) | Rotation speed (RPM) | Needle type | Max. horizontal movement (mm) | Needle space (mm) | Power supply | Stitch size (mm) | Power (KW) |
YXS-64-2B | 3800* 1130* 1600 | 2000 | 1700 | 30 | 550 | 16#/19# | 210 | 25.4 | 380V/220V 50Hz/60Hz | 2-6 | 3 |
YXS-64-3B | 3800* 1200* 1600 | 2200 | 1700 | 30 | 550 | 16#/19# | 210 | 25.4 | 380V/220V 50Hz/60Hz | 2-6 | 3 |
YXS-94-2B | 4900* 1130* 1610 | 2700 | 2450 | 30 | 550 | 16#/19# | 260 | 25.4 | 380V/220V 50Hz/60Hz | 2-6 | 4 |
YXS-94-3B | 4900* 1200* 1610 | 2900 | 2450 | 30 | 550 | 16#/19# | 260 | 25.4 | 380V/220V 50Hz/60Hz | 2-6 | 4 |
YXS-118-2B | 5500* 1150* 1750 | 3200 | 3000 | 30 | 500 | 16#/19# | 280 | 25.4 | 380V/220V 50Hz/60Hz | 2-6 | 5 |
YXS-118-3B | 5500* 1200* 1750 | 3500 | 3000 | 30 | 500 | 16#/19# | 280 | 25.4 | 380V/220V 50Hz/60Hz | 2-6 | 5 |
YXS-128-2B | 5800* 1150* 1750 | 3800 | 3250 | 30 | 500 | 16#/19# | 306 | 25.4 | 380V/220V 50Hz/60Hz | 2-6 | 5 |
YXS-128-3B | 5800* 1200* 1750 | 4200 | 3250 | 30 | 500 | 16#/19# | 306 | 25.4 | 380V/220V 50Hz/60Hz | 2-6 | 5 |
Yuxing Machinery Equipment Technology Co., Ltd is founded in 2002, located at Jiaoli Industrial Zone, Zhongtang Town, Dongguan City, Adjacent to the Dongguan bus station, connected the highway Guangzhou to Shenzhen and the Wuhuan Road, besides G107 with very convenient transportation. Our company produces the computerized high-end shuttle multi-needle quilting machine, computerized shuttle (lock stitch ) multi-needle quilting machine, non-shuttle(chain stitch) multi-needle quilting machine, quilting embroidery machine, cutting machine, and bobbin winder, with more than 10 kinds of producs, specialized in manufacturing computerized quilting machines, includng scientific research, process manufacturer and sales management and after service.
Successful implemented of the company into ISO9001: 2000 international Quality Managerment System, honored as "Private Scientific and Technological Enterprises"by Dongguan City Science&Technology office and Dongguan City Intellectual Property office. Our company owns about 200 workers. The machinery, automation, computers and over 20 technical engineers. It's good capability on products' development and improvement, owning lots of patents. In these years, Yuxing Machinery, owing to good quality and substantial price, have earned a hot market in China. We have established branches and dispatched technicians in over ten cities. At the same time, products are exported to Southeast Asia, Middle East, Europe, Oceania and Africa. Yuxing Machinery get a high credit standing at the correlative industry.
We always insist"Quality first, customer first, credit management, credit-oriented"purposes, in the highly competitive market conditions. We have been aggressive, innovative, self-developement in the competition, at the service of self-perfection, with modern business philosophy, excellent products, quality service to serve our customers.
