1.-35Years Experience 2.-Factory 3.-Own Exporting License 4.-Quality Control 5.-Own Technology 6.-Independent intellectual property 7.-Good Service
LB600, LB1000, LB1500, LB2000,LB3000,LB4000, LB Stationary Asphalt Mixing Plant Asphalt mixing plant has highly accurate aggregate feeder, high quality mix, high production rate,excellent asphalt mixing plant. The modular design and clearly defined interfaces between the asphalt mixing components allow the utilization of local manufacturing sources. The reduction of transportation and production costs is a direct benefit for our customers. The modular design and the preparation of the modules through the production lead to a fast and uncomplicated working site assembly.
Environment Protection
1.Total dust collection with 1st-level inertial collecting,2nd-level bag house and dust collecting modules for various portions of facilities
2.We establish environment protection concepts according to the European standards to achieve in dust emission, acid emission and noise control etc.
3.The facilities are in green harmony with the environment wherever we go
Features of Mobile Asphalt Batching Plant:
1. The loop belt feeder for the measuring hopper has a frequency-conversion speed regulator which can provide high and low speed. Its original structure facilitates belt change and makes material feeding more fluent, which reduces power consumption. Besides, there is a warning light which will remind the user when the machine uses up raw material.
2. The high-efficiency and heat preservation drying drum and the special vanes make heat exchange more sufficient. Moreover, the high-efficiency and energy-saving imported burner can use both heavy oil and diesel, which reduces energy consumption.
3. The vibrating screen adopts the linear and completely closed design with the vibrator placed outside. The sieving efficiency is high, the maintenance and changing of screen is easy, and the imported bearings are more reliable.
4. The hot aggregate bin is equipped with a continuous level indicator which enables the operator to know the level of material at a glance. The measurement of aggregate is conducted twice through large and small doors, which greatly improves the measuring precision. The unique structure of the material emptying door reduces the chance of blockage and will work more reliably.
5. The main mixing machine designed with European technology has double reducers with a high-speed synchronization capacity. Accurately weighed asphalt can be directly pumped into the agitating kettle and powder material can be conveyed into the agitating kettle through the helix, which makes agitating more even and speedy. Besides, it has an opening to add wood fiber and an inlet to add used material to be recycled.
6. The dust-removing system adopts imported NOMEX bags which limit the density of dust discharged into the air within 50mg/m³, which is completely up to the national standard of environmental protection. The dust blown down will be collected into the collection tank through the dust lifter for reuse to avoid secondary pollution.
7. The control system adopts the SIEMENS integrated solution which plays a leading role in the industrial automation field. It also uses the PROFIBUS field bus to form a large and medium-sized distributed automatic system. In operation, the equipment adopts the technology of double hot standby on the industrial computer, dynamic display and buttonless design. All operations are done through the mouse. It has the real-time fault monitoring and control system with functions like parameter setting, data management and fault diagnosis. It measures precisely and can be controlled automatically, semi-automatically and manually, showing a stable and reliable performance.
Main Technical paraments
| Type | LB600 | LB1000 | LB1500 | LB2000 | LB3000 | LB4000 |
| Rated production | 40t/h | 60t/h-80t/h | 120t/h | 160 t/h | 240 t/h | 320 t/h |
| Cold aggregate container | 4containers
×6m3 | 4containers
×6m3 | 4containers
×9m3 | 4containers
×9m3 | 5 containers
×11m3 | 5 containers
×11m3 | 5 containers
×11m3 |
| Dry cylinder | 1.1m×4.2m | 1.3m×5m | 1.5m×6m | 1.8m×7m | 2.2m×8m | 2.5m×10m | 2.8m×11m |
| Emission standard | 50mg/nm3 | 50mg/nm3 | 50mg/nm3 | 50mg/nm3 | 50mg/nm3 | 50mg/nm3 | 50mg/nm3 |
| Vibrating screen | 4 layers | 4 layers | 4 layers | 4 layers | 5 layers | 5 layers | 5 layers |
| Hot aggregate container | 12t | 12t | 26t | 26t | 5/40t | 80t | 100t |
| Mixing kettle capacity | 500kg | 750kg | 1000kg | 1500kg | 2000kg | 3000kg | 4000kg |
| Mixing cycle | 45s | 45s | 45s | 45s | 45s | 45s | 45s |
| Mineral powder tank volume | 30t | 30t | 26+36t | 26+36t | 30+43t | 50+35t | 60+35t |
| Asphalt tank volume | 30000L | 30000L | 50000L | 50000L | 2×50000L | 3×50000L | 4×50000L |
| Heat conduction oil stove | 200,000 kcol/h | 200,000 kcol/h | 300,000 kcol/h | 300,000 kcol/h | 500,000 kcol/h | 800,000 kcol/h | 1,000,000 kcol/h |
| End-product container volume | 50t | 50t | 90t | 90t | 110t | 200t | 200t |
| Control system | Manual /semi-auto / automatic |
| Weighing accuracy | Aggregate | ≤±0.4% | ≤±0.4% | ≤±0.4% | ≤±0.4% | ≤±0.4% | ≤±0.4% | ≤±0.4% |
| Powder material | ≤±0.3% | ≤±0.3% | ≤±0.3% | ≤±0.3% | ≤±0.3% | ≤±0.3% | ≤±0.3% |
| Asphalt | ≤±0.2% | ≤±0.2% | ≤±0.2% | ≤±0.2% | ≤±0.2% | ≤±0.2% | ≤±0.2% |
Installed
general power | 190kw | 210kw | 230kw | 320kw | 400kw | 720kw | 820kw |
XDE is shorted for Xiamen XDE Industry Co., Ltd., which is the international sales department of Quanzhou Road Machinery Factory established in 1980. We design, manufacture and market a wide range of mixing machinery for buildings and construction.
XDE has grown to become the professional market leader of CONCRETE BATHING PLANT, ASPHALT MIXING PLANT, CONCRETE MIXER, SOILE BASE MIXING PLANT, AND OTHER CONSTRUCTION MACHINES by being a customer-driven company. Through listening to our customers and understanding every aspect of their business, we are able to provide new products and increase profits. The machinery factory department occupies over 35, 000 square meters of modern manufacturing in Quanzhou, and the international sales department office located in beautiful coastal city in Xiamen, China.
Along with technologically advanced top line product, XDE focuses on providing excellent service. The company dispatches its service personnel all over the world to help set-up facilities and train operators. The service department offers technical assistance and troubleshooting for our products, even if the customer's problem does not involve our product. Additionally, XDE maintains a large replacement parts inventory for XDE and other brands and fills part orders quickly and efficiently.
XDE will continue to strive for new ways and better solutions. We look forward to serving our customers of today and tomorrow with innovative products and excellent service.
