Product Specifications
| Prod Model: |
JZB series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Refrigeration Equipment |
| Usage: |
Industrial |
| Product Type: |
cold room |
Product Description
The JZB series features by their Semi-Hermetic Bitzer compressor, it includes 4 series of products of air cooled and water cooled, middle and high, middle and low temperature range. All the products are applicable to the industries of food fresh keeping, cold storage, ice making, chilled water equipments etc.
Main components
World famous brand refrigeration parts are employed for all products:
Semi-Hermetic Bitzer compressor;
Copper tube & aluminum fin typ heat exchangers are employed for air cooled type products; Shell and tube type heat exchangers are employed for water cooled type products.
Built in water proof terminal box;
|
Model |
JZBF |
|
02M |
02M |
03M |
03M |
03M |
04M |
05M |
|
Compressor model |
2HC2.2 |
2GC2.2 |
2FC3.2 |
2EC3.2 |
2DC3.2 |
2CC4.2 |
4FC5.2 |
|
|
Te-5 |
Cap(kW) |
3.44 |
4.07 |
4.91 |
5.78 |
6.91 |
8.52 |
9.83 |
|
Input(kW) |
1.62 |
1.87 |
2.31 |
2.61 |
2.98 |
3.67 |
4.12 |
|
Te-7 |
Cap(kW) |
3.15 |
3.73 |
4.5 |
5.26 |
6.3 |
7.77 |
8.95 |
|
Input(kW) |
1.58 |
1.83 |
2.25 |
2.52 |
2.88 |
3.53 |
3.98 |
|
Te-10 |
Cap(kW) |
2.74 |
3.26 |
3.93 |
4.55 |
5.44 |
6.73 |
7.74 |
|
Input(kW) |
1.5 |
1.75 |
2.14 |
2.37 |
2.72 |
3.33 |
3.76 |
|
Room Tem |
-5 to 5 deg C |
|
Refrigerant |
R22 |
|
Power supply |
380V/3P/50Hz |
|
Condnsr |
Fan Qty |
1 |
1 |
1 |
2 |
2 |
2 |
2 |
|
Fan Voltage(V) |
380 |
380 |
380 |
380 |
380 |
380 |
380 |
|
Fan Input(W) |
180× 1 |
180× 1 |
180× 1 |
140× 2 |
140× 2 |
180× 2 |
180× 2 |
|
|
Gas dia(mm) |
φ 16 |
φ 16 |
φ 16 |
φ 22 |
φ 22 |
φ 22 |
φ 22 |
|
Liquid out(mm) |
φ 10 |
φ 10 |
φ 10 |
φ 12 |
φ 12 |
φ 12 |
φ 12 |
|
Overall sizes |
A (mm) |
790 |
790 |
790 |
790 |
960 |
960 |
960 |
|
B (mm) |
700 |
700 |
750 |
750 |
750 |
750 |
800 |
|
C (mm) |
598 |
648 |
648 |
698 |
648 |
799 |
849 |
|
Install sizes1(a× b)(mm) |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
|
Install sizes2(c× d)(mm) |
660× 320 |
660× 320 |
710× 320 |
710× 320 |
710× 320 |
710× 320 |
760× 420 |
|
Model |
JZBF |
|
06M |
07M |
09M |
10M |
12M |
15M |
20M |
|
Compressor model |
4EC6.2 |
4DC7.2 |
4CC9.2 |
4VCS10.2 |
4TCS12.2 |
4PCS15.2 |
4NCS20.2 |
|
|
Te-5 |
Cap(kW) |
12.08 |
14.76 |
17.84 |
19.58 |
23.6 |
28.3 |
32.8 |
|
Input(kW) |
5.12 |
6.14 |
7.5 |
7.43 |
9.13 |
10.45 |
12.6 |
|
Te-7 |
Cap(kW) |
11.02 |
13.47 |
16.29 |
17.95 |
21.7 |
25.9 |
30 |
|
Input(kW) |
4.93 |
5.95 |
7.27 |
7.19 |
8.84 |
10.12 |
12.15 |
|
Te-10 |
Cap(kW) |
9.54 |
11.67 |
14.15 |
15.69 |
18.96 |
22.6 |
26.2 |
|
Input(kW) |
4.65 |
5.65 |
6.92 |
6.82 |
8.39 |
9.6 |
11.46 |
|
Room Tem( |
-5 to 5 deg C |
|
Refrigerant |
R22 |
|
Power supply |
380V/3P/50Hz |
|
Condnsr |
Fan Qty |
2 |
2 |
2 |
2 |
4 |
4 |
4 |
|
Fan Voltage |
380 |
380 |
380 |
380 |
380 |
380 |
380 |
|
Fan Input(W) |
180× 2 |
250× 2 |
250× 2 |
250× 2 |
180× 4 |
180× 4 |
180× 4 |
|
|
Gas dia(mm) |
φ 28 |
φ 28 |
φ 28 |
φ 28 |
φ 35 |
φ 35 |
φ 42 |
|
Liquid out(mm) |
φ 12 |
φ 16 |
φ 16 |
φ 16 |
φ 16 |
φ 22 |
φ 22 |
|
Overall sizes |
A (mm) |
960 |
1640 |
1640 |
1640 |
1640 |
1860 |
1860 |
|
B (mm) |
800 |
800 |
850 |
850 |
900 |
950 |
950 |
|
C (mm) |
849 |
749 |
849 |
899 |
899 |
899 |
999 |
|
Install sizes1(a× b)(mm) |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
|
Install sizes2(c× d)(mm) |
760× 420 |
760× 420 |
810× 670 |
810× 670 |
860× 670 |
910× 470 |
910× 470 |
|
Model |
JZBF |
|
25M |
30M |
35M |
40M |
50M |
|
Compressor model |
4H25.2 |
4G30.2 |
6H35.2 |
6G40.2 |
6F50.2 |
|
Room Tem |
-5 to 5 deg C |
|
Refrigerant |
R22 |
|
Power supply |
380V/3P/50Hz |
|
Condnsr |
Fan Qty |
2 |
2 |
3 |
3 |
3 |
|
Fan Voltage(V) |
380 |
380 |
380 |
380 |
380 |
|
Fan Input(W) |
800× 2 |
800× 2 |
800× 3 |
800× 3 |
800× 3 |
|
|
Te-5 |
Cap(kW) |
42.8 |
49 |
64.2 |
73.6 |
87.4 |
|
Input(kW) |
16.1 |
19.04 |
24.2 |
28.6 |
35.5 |
|
Te-7 |
Cap(kW) |
39.2 |
45 |
58.9 |
67.5 |
80.3 |
|
Input(kW) |
15.61 |
18.46 |
23.4 |
27.7 |
34.4 |
|
Te-10 |
Cap(kW) |
34.3 |
39.4 |
51.5 |
59.1 |
70.4 |
|
Input(kW) |
14.83 |
17.57 |
22.3 |
26.4 |
32.8 |
|
|
Gas dia(mm) |
φ 54 |
φ 54 |
φ 54 |
φ 54 |
φ 54 |
|
Liquid out(mm) |
φ 22 |
φ 22 |
φ 28 |
φ 28 |
φ 28 |
|
Overall sizes |
A (mm) |
1860 |
1860 |
1161 |
1159 |
1580 |
|
B (mm) |
1125 |
1111 |
647 |
647 |
649 |
|
C (mm) |
1299 |
1499 |
889 |
889 |
889 |
|
Install sizes1(a× b)(mm) |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
130× 130 |
|
Install sizes2(c× d)(mm) |
960× 670 |
960× 670 |
510× 570 |
510× 570 |
510× 870 |
|
Condnsrsizes |
A (mm) |
1755 |
1755 |
2555 |
2555 |
2555 |
|
B (mm) |
1050 |
1050 |
1050 |
1050 |
1050 |
|
C (mm) |
1050 |
1050 |
1050 |
1050 |
1050 |
We are a leading refrigeration equipment manufacturer in China who produce refrigeration equipment like condensing units, air coolers, condensers etc.
