Product Specifications
| Prod Model: |
F2000 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Function: |
Automatic Control |
| Certification: |
CE |
| Task: |
Program |
| Condition: |
New |
Product Description
Summarize: The CNC system of F2000 uses ARM and DSP motor control IC to implement cutting control, and the system is widely applied to oxygen gas cutting and plasma cutting processing industry. The system is designed portably to be installed. The system is easy to be operated and the worker can use the menu and the graphical hints to operate it. All the key buttons are designed in ergonomic considerations to be used conveniently. The front USB port can import and export files conveniently. The system interface includes many languages such as Chinese simplified, English, Russian, French, Japanese and can be used in many countries.
Basic Parameters/ Hardware Configuration:
MCU: ARM9
Number of axis motion: Two axes motion interpolation (can be extended to three axes)
Max code lines: 150, 000 lines
Single cutting code size: 4MB
File memory space: : Electronic bulk memory chip, 512MB
User file memory space: 256MB
Controlling accuracy: ± 0.001mm (millimeter)
Coordinate range: ± 99999.99mm
Max pulse frequency: 250KHz; Max motion speed: 25m/sec.
Time resolving capability: 10ms
System power: DC +24V
System working condition: Temperature: 0º C - +55º C; Relative Humidity: 0-95%.
Interface: USB
Frame: Overall metal structure
Special configuration: Touch pad, 100m wireless remote controller and wire control box.
Support oxygen gas, plasma, powder and simulation demo mode.
Characteristics of System
45 categories different graphics (including grid pattern), chip part and hole part are alternative.
Graphics have some operations such as Proportion, Rotate, Mirror.
Graphics can be arrayed in matrix, interaction, stacked modes
According to plate thickness, the cutting speed is automatically restricted by a speed limit in the corner, effectively preventing over burn.
Metric system/ imperia system switch
Steel plate can be adjusted according any steel side.
Coordinate system can be customized to support the two-dimensional coordinates of all eight kinds.
All input and output port type and the number can be customized (normally open or normally closed)
System and parameters backup, update system online
Chinese / English (including Japanese, Russian, French and other languages )file system and menu can be switched only by one key.
Select row and column manually.
Support edge cutting and offset cutting.
Automatically memorize the working situation and the last cutting point when power off.
Dynamic/static illustration of the process, graphics zoom in / out, dynamically tracking cut-off point under zooming state.
Support artgrave, TYPEIII, PM2000 cam software
Set up different administration authority and the corresponding password to safeguard the interests of managers.
