Crawler Track Bulldozer T165-2 with Low Price for Sale! ! !
Product Specifications
| Prod Model: |
T165-2 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Operating Weight(Not Including Ripper): |
17800 Kg |
| Dozing Capacity: |
5 |
| Engine Flywheel Power: |
121kw |
| Overall Dimensions(Lxwxh): |
5416*3297*3160mm |
| Engine Model: |
Wd10g178e25 |
| Max. Digging Depth (Mm): |
500mm |
| Amt.of Supporting Wheel(Each Side): |
6 |
| Amt.of Carrier Wheel(Each Side): |
2 |
| Blade Width: |
4314 |
| Track Gauge: |
1880 |
| Type: |
Medium-sized Loader |
| Walking Mode: |
Crawler |
| Load And Unload Method: |
Front Discharge |
| Certification: |
ISO9001: 2000 |
| Condition: |
New |
Product Description
T165-2 Bulldozer is 165 horsepowe track-type dozer with hydraulic direct drive, semi-rigid suspended and hyraulic assisting operating, pilot hyraulic blade control. T165-2 bulldozer is characterized by high efficent, open view, optimized structure, easy operation and service with low cost and reliable entire quality. It can be equipped with three shanks ripper, U-blade (7.4m3) and other optional components. T165-2 bulldozer is applicable for earth handling in road construction, desert and oil-field working, farmland and port construction, irrigation and electric power engineering, mining and other engineer conditions. It is the upgrade product of T165 -2 bulldozer.
Technical Parameters
| Dozer | Tilt |
| Operation weight | 17800 |
| Ground pressure(KPa) | 69 |
| Track gauge(mm) | 1880 |
| Gradient | 30°/25° |
| Min. ground clearance (mm) | 352 |
| Gradient | 30°/25° |
| Dozing capacity (m³) | 5.0 |
| Blade width (mm) | 3297 |
| Max. digging depth (mm) | 592 |
| Overall dimensions (mm) | 5416×3297×3160 |
| Engine |
| Type | WD10G178E25 |
| Rated revolution (rpm) | 1850 |
| Flywheel power (KW/HP) | 121/165 |
| Max. torque (N?m/rpm) | 830/1100 |
| Rated fuel consumption(g/KW?h) | ≤218 |
| Undercarriage system | |
| Type | Swing type of sprayed beam.Suspended structure of equalizer bar |
| Number of track rollers (each side) | 6 |
| Number of carrier rollers (each side) | 2 |
| Pitch (mm) | 203 |
| Width of shoe (mm) | 500 |
| Gear | 1st | 2nd | 3rd |
| Forward (Km/h) | 0-3.9 | 0-6.5 | 0-10.9 |
| Backward (Km/h) | 0-4.8 | 0-8.2 | 0-13.2 |
| Implement hydraulic system |
| Max. system pressure (MPa) | 12 |
| Pump type | Two groups Gears pump |
| System output(L/min) | 190 |
| Driving system |
| Torque converter | 3-element 1-stage 1-phase |
| Transmission | Planetary, power shift transmission with three speeds,Forward and three speeds reverse, speed and direction,can be quickly shifted. |
| Steering Clutch | Multiple-disc oil power metallurgy disc compressed by spring. hydraulic operated. |
| Braking clutch | Brake is oil two direction floating band brake operated by mechanical foot pedal. |
| Final Drive | he final drive are double reduction with spur gear and segment sprocket. |
LuoYang Silon Industrial Co., Ltd is a leading Chinese construction machinery exporter, located in the city of Luoyang, which is known as the "Millennium Imperial City'' and ''The City of Peony". Since our company was founded, based on the advantage of XCMG which is the No. 1 Chinese construction machinery manufacturer, we continually introduce top Chinese construction machinery enterprises and their products to international markets, such as Changlin, Zoomlion, LiuGong, Foton Lovol, HBXG, Hyundai, Komatsu, YTO etc.
As the authorized dealer of XCMG and also With "Customer First" as our constant serving tenet, Silon Industrial has emerged as a renowned exporter of a wide range of top Chinese Construction Machinery., We won the good fame and reputation from reliable quality, competitive price and excellent after-sales service, We will scrupulously abide by our management concept of "Honesty, Professional, and Win-Win".
With a rich experience of many years, we have acquired the requisite expertise and excellence in our domain. Having scaled phenomenal heights of success, today we stand tall amidst a number of competitors across the world. A well coordinated and expertly managed operation system and professional international sales team enable us to turn orders into final products and export them to approximately 60 countries and several regions across the globe.
Product Range:
Silon Industrial brings you a wide range of construction machinery series, as follows:
- Lifting Machinery, such as Truck Crane, All Terrain Crane, Rough Terrain Crane, Truck-mounted Crane
- Earthmoving Machinery, such as Wheel Loader, Mini Loader, Excavator, Bulldozer, Backhoe Loader, and Skid Steer Loader
- Road Construction Machinery, such as Road Roller, Motor Grader, Asphalt Paver, Cold Milling Machine
-- Concrete Machinery, such as Concrete Pump, and Concrete Mixer
-- Logistics Machinery, such as Telescopic Handler, and Forklift
- Special Vehicle, such as Dump Truck, Semi Trailer, Aerial Work Platform, and Fire Truck, Bitumen tanker
Our Advantage
- Professional sales team consisted of diligent, dynamic and innovative people with international version.
-- Excellent logistics services ensuring timely delivery of consignments all over the world through ocean, airline, road and railway.
-- Well coordinated and expertly managed operation system adapted.
-- Expert team of after-sales professionals assuring that all our products under excellent maintenance and performance.
Silon Industrial is distinguished by a highly collaborative culture which values the contribution of our diverse team both within the company and in the wider community. Our style is open, service focused, and friendly. We believe that our commitment to client service, commerciality, and teamwork provides benefits to our clients and enhances effective business relationships.
