Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB,CFR,EXW |
Min Order: | 2/Piece |
Pay Type: | T/T,Western Union,Money Gram |
Prod Model: | CA18 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Rated Power: | 1300W Per Channel |
Peak Power At 2ohms Stereo: | 5200W Per Channel |
Protection 1: | DC Protection |
Protection 2: | Short Circuit Protection |
Protection 3: | Sensitivity Overheating Management System |
Protection 4: | Overhear Protection |
Protection 5: | Input Overload Protection |
Protection 6: | Output Overload Protection |
Protection 7: | Soft Start Protection |
Protection 8: | Limiting Protection |
Noise: | ≥105dB |
Hi-Fi: | Not Hi-Fi |
Speaker Material: | Metal |
Application: | Commercial |
THD: | <0.005% |
Operation Mode: | Cable Connection |
Speaker System: | Amplifier |
Certification: | SGS |
Monitor: | No LED |
Technical Specification | CA4 | CA6 | CA9 | CA12 | CA18 | |
PMPO peak power | 4 ohmsBridge | 2100 | 2950 | 3200 | 3800 | 4600 |
8 ohmsBridge | 1600 | 2300 | 2600 | 3450 | 4100 | |
2 ohms Stereo | 1200 | 1550 | 1850 | 2100 | 2850 | |
4 ohms Stereo | 900 | 1250 | 1400 | 1750 | 1950 | |
8 ohms Stereo | 600 | 800 | 1000 | 1200 | 1400 | |
20Hz-20KHz, ≤ 0.1%THD rated power | 4 ohms Bridge | 1750 | 2500 | 2750 | 3000 | 4100 |
8 ohms Bridge | 1350 | 2100 | 2350 | 2600 | 3750 | |
2 ohms Stereo | 980 | 1250 | 1600 | 1800 | 2400 | |
4 ohms Stereo | 750 | 900 | 1250 | 1400 | 1850 | |
8 ohms Stereo | 400 | 600 | 800 | 1000 | 1300 | |
safe protection | Dc protection | √ | ||||
Short circuit protection | √ | |||||
Sensitivity overheating management system | √ | |||||
Overheat protection | √ | |||||
Input overload protection | √ | |||||
Output overload protection | √ | |||||
Soft start protection | √ | |||||
Limiting protection | can reach 10V | |||||
Frequency Response | 20Hz-20KHz± 3dB | |||||
Sensitivity | 0.775v | 0.775v | 0.775v | 0.775v | 0.775v | |
Link | Input | XLR 1/4Jack | XLR 1/4Jack | XLR 1/4Jack | XLR 1/4Jack | XLR 1/4Jack |
Output | SPEAKON | SPEAKON | SPEAKON | SPEAKON | SPEAKON | |
Filter electrolysis capacity | 40000uf | 40000uf | 60000uf | 60000uf | 60000uf | |
Input impedance | Balance input | 20Kohms | ||||
Unbalanced input | 10Kohms | |||||
String sound attenuation20Hz-20KHz, 8ohms | ≥ 65dB | |||||
8ohmsS/N | ≥ 108dB | |||||
Damping coefficient1KHz& 8ohms | ≥ 900 | ≥ 800 | ||||
Intermodulation distortion20Hz-20KHz | ≤ 0.02% | |||||
Total harmonic distortion20Hz-20KHz | ≤ 0.05% | |||||
Phase response1W& 8ohms, 20Hz-20KHz | ≤ ± 8° | |||||
Conversion rate | ≥ 60V/µ s | |||||
Output circuit type | H | H-II | ||||
Power consumption 4ohms, 1/8RMS/230V | 250 | 450 | 550 | 650 | 800 | |
Installation space | 2U | |||||
Cooling system | intelligent system, automatic adjustment according to changing temperature | |||||
Size(W× H× D) | 630× 590× 210mm | |||||
Net Weight | 20.25kg | 27kg | 28kg | 37kg | 38kg | |
Technical support and after-sales service | 1 years Warranty non-artificial damage |
