Customized Communication Antenna ARP-Dp (1800-2600) -9-2

Name: Customized Communication Antenna ARP-Dp (1800-2600) -9-2
Brand: china-manufacturer-directory.com
SKU: 710887055
Availability: InStock
Rating: 4.9 (127 reviews)

Supplier:	Shenzhen Arronna Telecom Co., Ltd.
Price:	Negotiable/Piece
Min Order:	10/Piece
Quantity::
Trade Terms:	FOB,others

Product Specifications

Prod Model:	ARP-DP(1800-2600)-9-2
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Lte Antenna
Frequency:	1800-2600MHz
Gain:	9dBi
Connector:	2*Sma Male
Polarization:	Vertical and Horizontal
Package:	20PCS Per Carton
Delivery Time:	7 Days
Guarantee Time:	3 Years
Company:	OEM,ODM Factory
Service:	24 Hours on Line
Usage:	Communication Antenna
Directionality:	Directional Antenna
Operating Wavelength:	Medium Wave
VSWR:	1.5~2
Material:	UV Protected ABS

Product Description

ARP-DP(1800-2600)-9-2, LTE Antenna is specially designed for 1800-2600MHz, dual polarization LTE communication and WLAN wireless network indoor bestrew system. It features wide bendwidth, share with GSM, CDMA and WLAN system.

1. Designed for wireless access system, Point-to-point sent and receive signal
2. Good standing wave performance
3. Big F/B ratio, 1800-2600
4. OEM and ODM antenna are available

Product Name	1800-2600MHz LTE panel antenna
Description	ARP-DP(1800-2600)-9-2: The panel antenna is designed for wireless access system. Which through optimization design and careful debugging with follow qualities: good standing wave performance,high gain,broad band,big F/B ratio,strong structure,own the good ability of antihunting,waterproof and anticorrosion; Small size,easy installation,the directional diagram will be unacted whether installate on iron tower or roof.
Electric Specification
Model NO	ARP-DP(1800-2600)-9-2:
Frequency Range-MHz	1800-2600
Bandwidth-MHz	800
Gain-dBi	9
Horizontal Bear width-°	70
Vertical Bear width -°	65
F/B Ratio	18
VSWR	≤1.5
Input Impedance -Ω	50
Polarization	Verticaland Horizontal
Maximum Power -W	50
Connector	2*N female
Mechanical Specifications
Dimensions-mm	23823050

Shenzhen Arronna Telecom Co., Ltd. was founded in 2007, mainly offer antenna OEM & ODM service for clients, mainly sector antenna, panel antenna, yagi antenna, fiberglass omni antenna at MIMO / LTE / WIMAX / WiFi / 3G / DECT / WLAN/ CDMA antennas. Shenzhen Arronna Antennas Co., Limited is an integrated high-tech company owning strong ability on R&D, production and selling. Welcome you to learn more about us.

Now ARRONNA owns more than 3, 000 square meters production area, about 80 staff (tech dept 6people, QC 6, the 40% staff has college background), 6 production line, more than 100 types of products covering frequency from 88MHz to 5.8GHz and these products has covered the following field such as WiFi / WIMAX wireless communication system, wireless data transmitting system, global position system, digital TV system and civil use. Now our products already work with 3G Telecom System, WiFi/WiMAX Telecom System, HUAWEI CPE and successfully worked with China MOBILE, GLOBE TELECOM and defeated many competitors to enter EU market, South-east Asia market and Asian Market.

Since founded, ARRONNA has developed fast by the clients' support! We strictly follow ISO9001: 2008 quality system to improve the architect and management style, and also use ISO14001: 2004 system to regulate and arrange production process. If we promise, you have my word! That is ARRONNA's motto! Hereby, ARRONNA sincerely welcome you visit our factory and give us your precious opinion, ARRONNA look forward to working with you soon!
