| Supplier: | Shaanxi HAVEN Equipment Co., Ltd. |
|---|---|
| Price: | Negotiable/Piece |
| Min Order: | 1/Piece |
| Quantity:: | |
| Trade Terms: | FOB,CFR,EXW |
|
|
| Prod Model: | CW62140Dx2000 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max Workpiece Weight: | 6t |
| Spindle Bore Dia: | 130mm |
| Type: | Horizontal Lathe |
| Automatic Grade: | Semiautomatic |
| Precision: | High Precision |
| Power Source: | Hydraulic Pressure |
| Setting Mode: | Floor-type |
| Controlling Mode: | Artificial |
| Tool Holder: | 4 Stations Tool Post |
| SPECIFICATION | Models | |||||
| CW612100D | CW612125D | CW612140D | CW612160D | CW612180D | ||
| CAPACITY | Swing dia. over bed | 1000 | 1250 | 1400 | 1600 | 1800 |
| Swing dia. over cross slide | 630 | 880 | 1030 | 1030 | 1030 | |
| Swing dia. on gap | 1450 | 1700 | 1850 | 2050 | 2250 | |
| Width of bed | 755mm | |||||
| Max. workpiece length | 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 | |||||
| SPINDLE | Spindle nose | A15 | ||||
| Spindle bore diameter | 130mm | |||||
| Taper of spindle bore | Metric No. 140 | |||||
| Range of spindle speed | 3.15-315r/min 21 kinds | |||||
| FEEDS | Longitudinal feeds range | 0.1-12mm/r 56 kinds | ||||
| Transversal feed range | 0.05-6mm/r 56kinds | |||||
| Metric tread range | 1-120mm 44kinds | |||||
| Inch tread range | 3/8-28teeth/inch 31kinds | |||||
| Modular thread range | 0.5_60mm 45kinds | |||||
| Pitch thread range | 1-56teeth/inch 25 kinds | |||||
| TAILSTOCK | Tailstock center taper | Morse No.6 | ||||
| tailstock center motion | 300mm | |||||
| Tailstock center diameter | 140mm | |||||
| MOTORS | Main motor power | 22kw | ||||
| rapid motor power | 1.5kw | |||||
| Cool pump power | 0.125kw | |||||
| 1. Four-jaw chuck φ1000 1set | 4. center 1pc | 7.Foundation screws 1set |
| 2. steady support(for more than 2m) 1 set | 5 center bush 1pc | |
| 3. following support (for more than 2m) 1 set | 6. tools 1set |
| (φ400-φ700) Steady support | 4. Chasing dial device |
| φ1250 4-jaw chuck φ1250 | 5. Inch leadscrew |
| Metric dial device |
| Models Length | CW61100D CW62100D | CW61125D CW62125D | ||||||
| Floor space LxWxH | Packing dimension LxWxH | Net weight | Grossweight | Floor space LxWxH | Packing dimension LxWxH | Net weight | Grossweight | |
| 1000 | 4100x2100x1790 | 4430x1800x2290 | 9300 | 10000 | 4100x2100x1915 | 4430x1800x2290 | 9800 | 10300 |
| 2000 | 5100x2100x1790 | 5430x1800x2290 | 10000 | 11000 | 5100x2100x1915 | 5430x1800x2290 | 10500 | 11500 |
| 3000 | 6100x2100x1790 | 6430x1800x2290 | 10700 | 12000 | 6100x2100x1915 | 6430x1800x2290 | 11200 | 12500 |
| 4000 | 7100x2100x1790 | 7430x1800x2290 | 11400 | 13000 | 7100x2100x1915 | 7430x1800x2290 | 11900 | 13500 |
| 5000 | 8100x2100x1790 | 8430x1800x2290 | 12100 | 14000 | 8100x2100x1915 | 8430x1800x2290 | 12600 | 14500 |
| 6000 | 9100x2100x1790 | 9430x1800x2290 | 12800 | 15000 | 9100x2100x1915 | 9430x1800x2290 | 13300 | 15500 |
| 7000 | 10100x2100x1790 | 10430x1800x2290 | 13500 | 16000 | 10100x2100x1915 | 10430x1800x2290 | 14000 | 16500 |
| 8000 | 11100x2100x1790 | 11430x1800x2290 | 14200 | 16870 | 11100x2100x1915 | 11430x1800x2290 | 14700 | 17370 |
| 9000 | 12100x2100x1790 | 12430x1800x2290 | 14900 | 18000 | 12100x2100x1915 | 12430x1800x2290 | 15400 | 18500 |
| 10000 | 13100x2100x1790 | 13430x1800x2290 | 15600 | 19000 | 13100x2100x1915 | 13430x1800x2290 | 16100 | 19500 |
| Models Length | CW61140D CW62140D | CW61160D CW62160D | ||||||
| Floor space LxWxH | Packing dimension LxWxH | Net weight | Gross weight | Floor space LxWxH | Packing dimension LxWxH | Net weight | Grossweight | |
| 1000 | 4100x2100x1990 | 4430x1800x2290 | 10000 | 10700 | 4100x2100x2090 | 4430x1800x2290 | 10200 | 10900 |
| 2000 | 5100x2100x1990 | 5430x1800x2290 | 10700 | 11700 | 5100x2100x2090 | 5430x1800x2290 | 10900 | 11900 |
| 3000 | 6100x2100x1990 | 6430x1800x2290 | 11400 | 12700 | 6100x2100x2090 | 6430x1800x2290 | 11600 | 12900 |
| 4000 | 7100x2100x1990 | 7430x1800x2290 | 12100 | 13700 | 7100x2100x2090 | 7430x1800x2290 | 12300 | 13900 |
| 5000 | 8100x2100x1990 | 8430x1800x2290 | 12800 | 14700 | 8100x2100x2090 | 8430x1800x2290 | 13000 | 14900 |
| 6000 | 9100x2100x1990 | 9430x1800x2290 | 13500 | 15700 | 9100x2100x2090 | 9430x1800x2290 | 13700 | 15900 |
| 7000 | 10100x2100x1990 | 10430x1800x2290 | 14200 | 16700 | 10100x2100x2090 | 10430x1800x2290 | 14400 | 16900 |
| 8000 | 11100x2100x1990 | 11430x1800x2290 | 14900 | 17570 | 11100x2100x2090 | 11430x1800x2290 | 15100 | 17770 |
| 9000 | 12100x2100x1990 | 12430x1800x2290 | 15600 | 18700 | 12100x2100x2090 | 12430x1800x2290 | 15800 | 18900 |
| 10000 | 13100x2100x1990 | 13430x1800x2290 | 16300 | 19700 | 13100x2100x2090 | 13430x1800x2290 | 16500 | 19900 |
