Product Specifications
| Prod Model: |
FV20C/2-100 PVS |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Imax: |
40ka |
| In: |
20ka |
| Uc: |
100V |
| Color: |
Gray |
| Type: |
Power Source Arrester |
| Brand: |
Fatech |
Product Description
1. DC surge prodection for low-voltage power system Characteristic FV20C/2-100 PV S
-DC surge arrestors specially used for solar photovoltaic system 150Vdc.
-The core parts are metal oxide vristor components with high discharge capacity.
-With Reliable control thanks to Thermo Dynamic Control disconnector.
-With remote signaling contact for control device.
-Fault indication via red mark in the inspection window.
2. DC surge protector for low-voltage power system Electrical parameters FV20C/2-100 PV S
Model No.: FV20C/2-150 PV S | | | |
| Max.continuous DC voltage[(L+/L-)->PE]/ [L+->L-] | Uc pv | V | 100 |
| Requirement class to DIN EN 61643-1:2005 | | | Class C |
| Nominal Discharge current(8/20μs) | In | kA | 20 |
| Max. discharge current (8/20μs) | Imax | kA | 40 |
| Voltage protection level (at In) [(L+/L-)->PE]/ [L+->L-] | Up | kV | ≤0.8 |
| Response time | tA | ns | <25 |
| Operation temperature range | | | -40ºC~+85ºC |
| Degree of protection | | | IP20 |
| Remote control contacts | | | Yes
|
3. Company information
Fatech Electronic (FOSHAN) Co., Ltd is a professtional manufacturer of lightning and surge protection products. The trademake is is "FATECH".
Main Products:
- Surge arresters for protection of photovoltaic system ,
- Surge protection devices for protection of power supply systems,
- SPD surge protectors for protection of signal system,
- Lighting rod,
- Test devices.
Quality &Standards:- Products are producted perISO9001:2008, IEC61643-11, EN 50539-11, CE, CNAS, iLAC etc.
We have an independent testing laboratory, and a complete set of advanced testing equipment, including impulse current generator, the SPD Test System of Thermal Stability, varistor tester, lightning device tester, & TOV testers. We built up a complete quality control system, and strict process control system, product's stability & reliability are qualified by users.
Main markets: 80% export, mostly to Europe, which including France, Cyprus, Greece, Czech Republic, Poland, Spain, Austria, Hungary, Switherland, Italy, Russia, Finland, Turkey, Slovenia, Ireland; and Asia, South America, Africa & other worldwide markets.
We are trying to develop Fatech into a world-class Electrical manufactures
Fatech Electronic (Foshan) Co., Ltd., is a professional manufacturer on R&D, production and sales of lightning and surge protection products. We have two centers (R & D center, marketing center) and joint venture manufacturing bases in China.
Our main products including:
- Surge arresters for protection of photovoltaic system,
- Surge protection devices for protection of power supply systems,
- SPD surge protectors for protection of signal system,
- Lighting rod,
- Test devices,
- Metal oxide varistors.
Wide range of lighting & surge protection products assured you a one stop shopping location for all your need and professional technical support.
We have an independent testing laboratory, and a complete set of advanced testing equipment, including impulse current generator, the SPD Test System of Thermal Stability, varistor tester, lightning device tester, & TOV testers. We built up a complete quality control system, and strict process control system, product's stability & reliability are qualified by users.
Our company gathered authority technical experts and professionals, including 2 senior engineers, 5 engineers, and 11 excellent technicians with more than five years experience in lightning and surge protection industry. FATECH is well-known registered trademark, our products have achieved certificates of CE, and the company is achieved ISO9001-2008 quality system.
Based on our superior location advantages (It needs 50 minutes drive from Guangzhou Baiyun International Airport, 2 hours drive from Hong Kong), adhering to the business philosophy - "quality first, customer first, sustainable development", we are encouraging independent innovation, brand influence is increasing day by day, the products is selling to more than 30 countries in Europe, Latin America, Asia-Pacific and other regions.
Here are the advantages of us:
1. Stable Quality --- Product performance is stable and reliable.
2. Competitive Price --- Strict cost control system achievements very competitive prices.
3. Fast and always on-time delivery --- Leading technology and production capacity advantage make sure the short & fast delivery and always on-time.
4. ODM & OEM service supplied --- We are able to make not only standard surge protection devices, but also special products according to customer's requirement...
5. Professional on R&D and manufacturing --- With the capability and experience to provide customers with lightning and surge protection applications solutions
