Product Specifications
| Prod Model: |
CM2000W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Charge Current: |
10A |
| AC Output Frequency: |
50Hz/60Hz (Optional) |
| Color: |
Silver / Black (Optional) |
| Type: |
DC/AC Inverters |
| Phase: |
Single |
| Power Source: |
Electric Power |
| Output Power: |
>1000W |
| Brand: |
Chaomin |
Product Description
DC12V TO AC220V 2000W inverter with battery charging
Packaging & Delivery
Packaging Details: Plastic; Box paper packing
Delivery Detail: Within 15-25 working days after comfirming the payment
Specifications
1. Material: Alloy Aluminous
2. Warranty: 12 months
3.90% output efficiency
4. CE approval
5. Used in home, car/camping
6. Imput 12V/24V, output110V/220V
Features:
20A Charge Current Inverter
AC Output Waveform: Modified Sine Wave Inverter
Car Power Inverter.
Power Inverter with Charger.
50Hz/60Hz (Optional)AC Output Frequency Power Inverter.
Input and output isolated.
High surge and efficient.
No influence in appliances work when public power off.
Eight Protection Function
1: High voltage protection
2: Low voltage protection
3: Over load protection
4: Over temperatuer protection
5: Overcurrent protection
6: Output short-circuit protection
7: Positive and negative reverse polarity protection
8: Damage protection
Scope of use: Notice Ideally suitable for Journeys, Camping, Tents, Boat Trip,
Solar panel Working on the way and everywhere, where is no electricity! Simply
Connect with 12V/24V Battery as in a Car, Motorcycle, Camper or Boat and use
110V/ 220V electrical appliances.
Notice:
Power inverter ideally suitable for traveling, Camping, Tents, or boat Trip, and the Solar panel was used here and there, whatever where is no electricity!
Just connect with 12V/24V Battery as in a Car, Motorcycle, Camper or Boat and use 110V/ 220V electrical appliances
Product Including:
Car Inverter; Solar inverter; Pure sine wave invertre; Modify sine
Wave inverter; UPS inverter and so on.
Our products usually are exported big quantity in to Europe
, USA, African, Russia, Australiaetc. And our power inverter serials enjoy
Better reputation. We have good after sale-service tracking service system.
No matter connector to Autos cigaret lighter socket or other 12V batteries, can it supply sound AC power for household appliances, official equipments and other electrical devices, such as, TV sets, Electric fan, Refrigerator, lighting lamps, DVD, Amplifier, Audio, Video cam, electrical tools, fax simile, Photocopy machine, laptop. It is a necessity at field operation, driving travelling, mobile office and power-off emergency, which become the best solution to the urgent demand of power supply on the occasions of driving and power shortage.
Application
1. Travel Equipment Series: Military vehicle, police cars, ambulances, ships, traffic lights and so on
2. Industrial equipment series: Solar energy, wind power, metal halide lamps, high pressure sodium lamp and so on
3. Office equipment series: Computers, printers, monitors, copiers, scanners, digital cameras, digital cameras and so on
4. Home Equipment Series: Vacuum cleaners, fans, lights, electric cutting knife, sewing machines and so on
5. Kitchen utensils series: Microwave ovens, electric sheet metal pot, refrigerator and so on
6. Power tools: Saws, drilling machines, grinding machine, sandblasting machine, stamping machine, lawn mower, air compressor and so on
7. Series of electronics: TV, DVD, game consoles, power amplifiers, audio equipment, monitoring equipment, servers, satellite communications equipment
(To know more about our products, welcome to contact me anytime. )
| Function details: |
| Model | 2000W |
| peak Power | 4000W |
| DC input voltage | 12V , 24V |
| AC output voltage | 220v ,110V |
| AC output frequency | 50Hz/60HZ |
| AC output waveform | Modified sine wave |
| Waveform Distortion | THD<2%(Linear load) |
| Efficiency | >90% |
| DC input voltage range | 10V-15V or 20V-30V |
| Low Voltage Alarm | 11V+/-0.5V or 21+/-0.5V |
| Low Voltage Shutdown | 10V+/-0.5V or 20V+/-0.5V |
| Over Voltage Protection | 15.5+/-0.5V |
| Low Voltage Recovery | 12+/-0.5V or 24+/-0.5V |
| Over Voltage Recovery | 15V+/-0.5V or 29V+/-0.5V |
Protective Function | Low/Over voltage: LED Red light, automatic recovery |
| Over load: LED ,Red light ; automatic recovery |
| Over temperature : LED ,Red light,;automatic recovery |
| Short circuit: LED ,Red light; automatic recovery |
| Input reverse connection: Fuse burn-out |
| Working Temp. | –10°C_+60°C |
| Dimension | 420*205*80MM |
| Gross Weight | 3KG |
| Storage Temp. Humidity | -30°C-+70°C |
| Color | Silver ,black |
| Plug type | Universal, German, UK, France, USA, Australian etc |
| Warranty | 12 months |
