Product Features:
1. Cost-effective, durable, shorter lead time;
2. No blind spots, high precision, and long measurement distance;
3. Not affected by change of pressure, vacuum, dust, and steam, etc;
4. Easy installation, maintenance-free;
5. Communication protocols, simple calibration;
6. Sensitive measurement, high refresh speed;
7. Suitable for high temperature conditions;
8. Affordable, long-term life.
Technical Parameter:
Application
Hygienic liquid storage container, strong corrosive container
Measuring range
20 meter
Process connection
Screw, Flange
Medium Temperature
-40~150° C
Process pressure
Atmospheric
Precision
± 3mm
Frequency range
26GHz
Anti-explosion/safety grade
Exib IIC T6 Gb /IP67
Signal output
4...20mA/HART(Two-wire/ Four)
Model selection:
License
P standard (non-Ex)
I Intrinsically Safe (Exib IIC T6 Gb)
D intrinsically safe explosion-proof (Exd [ib] ib IIC T6 Gb)
Process connection/ Material
G thread G11 / 2A / stainless steel 304
N Threaded 11 / 2NPT / stainless steel 304
B flange DN80 / stainless steel 304
C flange DN100 / stainless steel 304
D flange DN125 / stainless steel 304
E flange DN150 / stainless steel 304
F flange DN200 / stainless steel 304
H flange DN250 / stainless steel 304
M flange DN80 / universal joint (stainless steel) 304
K flange DN100 / universal joint (stainless steel) 304
T flange DN125 / universal joint (stainless steel) 304
Z flange DN150 / universal joint (stainless steel) 304
W flange DN200 / universal joint (stainless steel) 304
V flange DN250 / universal joint (stainless steel) 304
Y special custom
Antenna Type/ Material
B horn antenna Φ76mm / stainless steel 304
C horn antenna Φ96mm / stainless steel 304
D horn antenna Φ121mm / stainless steel 304
Seal/ process temperature
V Viton / (- 40 ~ 120) ° C
K Kalrez / (- 40 ~ 250) ° C
Electronics unit
2 (4 ~ 20) mA two-wire
3 (4 ~ 20) mA / (24) VDC / HART two-wire
4 (4 ~ 20) mA / (~ 24) VDC / HART four-wire system
5 (4 ~ 20) mA / (~ 220) VAC / HART four-wire system
Housing/ Protection class
L aluminum / IP67
G stainless steel 304 / IP67
Cable entry
M M20xl. 5
N 1/2 NPT
Live display/ programming
A band
X without
Special convention
Y
Xi`an Dechuang Electrical Technology Co., Ltd. Is located in Xi'an High-tech Industrial Development Zone, is a professional high-tech enterprise committed to the power system protection and intelligent radar level gauge hardware and software research and development, production and sales.
The company has a number of high-quality modern enterprise management personnel and sales teams, both of them engaged in industrial automation systems design for many years. In recent years, the company relies on university research strengths, provide users with advanced technology, reliable automation products and dedicated after-sale service.
The main products are power monitor series and radar level gauge series. The level measurement product includes the 26G high frequency radar level gauge, 6.8G intelligent radar level gauge, guided radar level gauge. These products are widely used in electricity, water, petroleum, petrochemical, coal, metallurgy industry.
The company adhere to the principle "people-oriented, technology advanced, quality first, integrity and pragmatic" and supply customer with the reliable product.
