Wide belt grinding finishing machine Model: SG1650-WJS+B
For the grinding on the NO. 1 Stainless steel
Jonsen's machine of SG1600 series, with the maximum working width is 1580mm. It is specially designed for the work piece and coiled sheet over 1219mm wide. Wet abrasive belt combined with non-woven fabric brush enables a distinct grain, fine feel and high finish to the work piece. It is also able to work with the winding and unwinding machine to form a grinding line for coiled sheet, which is possible to bring an excellent finish even to the sheet as thin as 0.5mm. It is recommended to be the suitable equipment for surface grain treatment.
| Maximum working width(mm) | 1580 | Feed speed(m/min) | 2-14 |
| Minimum working length(mm) | 500 | Filter power (KW) | 1.37 |
| Working thickness(mm) | 0.5-20 | Total motor power(kw) | 81.5 |
| Size of belt(mm) | 1600× 2620 | Weight(t) | 8.0 |
| Dimension(mm) | 3300× 3000× 2250 |
Hangzhou Xiangsheng Abrasive Machine Manufacturing Co., Ltd. is specialized in metal surface processing equipment. We are devoting into metal grinding deburring and finishing in the past 21years and become the leader in this industry.
We are paying close attention to the advanced technologies and customers' Requirement, so every machine is with definitude function. In 2005, Jonsen' S products entered market of Europe and USA. The high ratio performance & price gets good reputation of customers all over the world.
The company' S management system was certificated in accordance with ISO9001: 2008. It successfully obtained CE in 2005. The compant passed through the ISO14000 in 2007. We believe that professionalism is the best solution! .
Established by Mr. Xiangsheng Chan, Jonsen started the abrasive belt jointing work in 1993, then we has been devoting to the belt grinding till today.
Now, we are servicing customers over world various of products: Wide belt grinding machine, graining, edge rounding, deburring machine, finishing machine, linishing machine, stroke sander, coil to coil and sheet to sheet grinding finishing line etc.
For the consumer products like abrasive belt for all size, top-brush, scotch brite brush, finishing brush, disk brush, steel wire brush, we are willing to share the use experience with you.
