Product Specifications
| Prod Model: |
JTL-0910, JTL-1110, JTL-1212 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product: |
Decorative Watch PVD Ion Plating Machine |
| Service: |
Installation, Training, PVD Solutions |
| Chamber Size: |
D900mm*H1000mm, D1100mm*H1000mm |
| Bigger Size: |
D1350mm*H1200mm |
| Coating Color: |
Gold, Rosegold, Silver, Black, Blue etc. |
| Coating Film: |
Tin, Tic, Ticn, Tialn, Crn, Cu, Au etc. |
| Coating Technology: |
Magnetron Sputtering+Multi-Arc Ion Coating |
| Application: |
Jewelry, Watch, Mobile Phone Shell etc. |
| Control Mode: |
Automatic PLC Touch Screen Control |
| Brand: |
Hcvac-Huicheng Vacuum |
| Coating: |
Vacuum Coating |
| Type: |
Watches Decorative Metal Ion Coating Machine |
| Certification: |
CE, ISO9001 |
| Substrate: |
Watches Decorative Metal Ion Coating Machine |
Product Description
Decorative watch pvd ion plating machine/physical vapor deposition process golden plating equipment has the features of fast deposition rate, great ionization rate, of efficiency, harmless and pollution-free. It has the features of fast deposition rate, great ionization rate, big ion energy, easy operation, low cost, large productive capacity, etc.
Applied industry: It is widely used in the watchband, watchcase, jewelry, mobile shell, hardware, tableware, etc. It can coat TiN, TiC, TiCN, TiAlN, CrN, Cu, Au, Al2O3and other decorative films. It can get fineness and smooth film, good adhesion.
MF sputtering technique has become the mainstream technology of sputtering, what characteristics superior to the DC sputtering are:
1. Overcome the phenomenon of anode disappearance.
2. Reduce or eliminate the abnormal arc discharge of target, therefore, improving the stability of sputtering process technology, while increasing the deposition rate of dielectric coating.
It can also coat the jeweries, mobile phones, golf head glass, ceramic etc.
We can design the dimension of the equipment according to customers special technique requirement.
Company Introduction:
HCVAC can help you to enter the PVD coating easily by our vacuum coating machine and full range service. We will provide with most suitable technology according to your requirements.
We will make the special coating solution for each customer; Combine the full set production technics to meet your requirements, to ensure high efficiency of production.
We developed a complete after-sales system and effective service measures. Company now owns a professional after-sales service team with more than ten experienced engineers.
ISO 9001 standard to ensure the quality can meet the customer's requirements.
Please feel free to contact us for further information!
Contact: Kelly Luo
Mobile: 0086-13650364433
Mode
Dimension | JTL-900 | JTL-1100 | JTL-1300 | JTL-1600 |
| Φ900*1000mm | Φ1100*1000mm | Φ1300*1200 mm | Φ1600*1300 mm |
Coating mode and main confirguration | 3 electric-arc+2 pairs of plane rectangular cathode | 6 electric-arc+2 pairs of cylindrical cathode+a pairs of plane rectangular cathode | 6 electric-arc+4 pairs of cylindrical cathode+a pairs of plane rectangular cathode | 8 electric-arc+8 pairs of cylindrical cathode+a pairs of plane rectangular cathode |
| Application | metal decorative coating |
| Film Types | Metal films,Dielectric films,Compound films,Reaction films,Muti-layer function films |
| Power source | Electric arc power supply,DC magnetron power supply,MF magnetron power supply.Pulse bias voltage power supply.ion source power supply. |
| Process gas control | Quality flowmeter + electromagnetism ceramic valve |
| Vacuum chamber structure | Vertical single(side) door, pump system postposition, double water-cooling |
| Vacuum system | Molecule pump(diffusion pump)+Roots pump +Mechanical pump (8.0*10 -4 Pa) |
| Pumping speed | Pumping time less than 15 minutes ,from atmospheric pressure to 310 -3 Pa |
| Workpiece baking temperature |
Normal temperature to 350 centi-degree PID control, radiation heating. |
| Workpiece motion mode | Public rotation Frequency control: 0-20 rotation per minute |
| Measure mode | Number display composite vacuum gauge: from atmosphere to 1.0*10 -5 Pa |
| Control mode | Full automation control system PC+PLC/PC+HMI |
| Remark | We can design the dimension of the equipment according to customers special technique requirement. |
DongGuan HuiCheng Vacuum Technology Co., Ltd is a high-tech enterprise specialized in the R&D, Production and Marketing of various kinds of the vacuum equipments. Our company aggregates many excellent technicians in the vacuum industry, including engineers with the senior and middle technique titles. We also invite the senior experts and experienced technicians to be responsible for the development and design of the new products, insure the high technology and quality of the vacuum equipment. Our products are popular with both the domestic and overseas clients, and have a high reputation in the vacuum industry.
Our company is dedicated to the R&D of the series of the vacuum coating machine. We have been designed various coating technics projects according to different requirements successfully, especially in the fields of mobile(computer) shell, electronical appliance, metal, auto parts and high-tech industries, etc. Particularly we designed the special wheels coating machine for the VIP enterprise in Zhejiang Province in 2007, bringing great benifits for the client, making prominent contribution to the environment protection and generating extremely positive social effectiveness. It is high appreciated by the government and craft brother. Therefor this project is listed to the item of the Nation Star Project. Our main products also include slide valve vacuum pump, Roots vacuum pump, water ring vacuum pump, rotary-vane vacuum pump, various vacuum units and different vacuum heating energy equipments, etc.
Our company sticks to the selling concepts of"People-Oriented, Keeping improving, Innovative and Factualistic, Customer First"; Holding the management policy of "Keep the science and technology ahead, Put quality and service at the first place"; Carrying forward our corporate spirits"Honesty and High efficiency, Unity and Struggle, Factualic and Innovative". We'll continue to hold the development and improvement as our main rhythm, stepping forward to the goal of becoming diversification, internationalization and high technological modern enterprise. We will make new contribution to set up the international advanced level in the vacuum fields.
