Deep Cycle Battery 2V1800Ah SMF Battery for off-Grid solar
CL2-1800
2V Lead Acid Batteries
Long life Rechargeable SMF Battery
CSPOWER 2V Valve regulated lead acid batteries series SMF batteries, ups batteries are designed with AGM (Absorbent Glass Mat) technology, high performance plates and electrolyte to gain extra power output for common power backup system applications.
Advanced Features:
1. Environmentally friendly
2. Completely Maintenance-Free
3. Non-Spillable construction design.
4. Wide OperatingTemperatureRange(-20~+60)
5. Longer Life(10-12years designed life)
6. Explosion Proof
7. Valve Regulated & High Discharge Rate Capability
8. Low Self Discharge
9. Independent of Position
10. Ease of Shipment
11. No need of balanced charge or boost
12. No Memory
| Capacity 77°F(25ºC) | 10 hours rate(150A 1.80V) | 1800Ah |
| 5 hours rate(268A 1.75V) | 1530Ah |
| 3 hours rate(378A 1.70V) | 1350Ah |
| 1 hour rate(920A 1.60V) | 990Ah |
| Internal Resistance | Full charged battery 77°F(25ºC):0.05mΩ |
|
| Capacity affected by Temperature (10 hour rate) | 104°F(40ºC) | 102% |
| 77°F(25ºC) | 100% |
| 32°F(10ºC) | 85% |
| 5°F(-15ºC) | 65% |
| Self-Discharge 68°F(20ºC) | Capacity after 3 month storage | 90% |
| Capacity after 6 month storage | 80% |
| Capacity after 12 month storage | 60% |
| Max discharge current77°F(25ºC):3000A(5S) |
| Charge (Constant Voltage) | Float:2.25 to 2.30V/77°F/(25ºC) |
| Cycle:2.35 to 2.45V/77°F/(25ºC) |
| Max Current:300A |
Application
- Solar power system
- Wind power system
- Emergency lighting system
- UPS and emergency power supply
- Control system
- Medical equipment
- Telecommunication/communication systems
About CSPOWER:
Our office is in Shenzhen, factories located in Dongguan and Shaoguan China.
We have obtained CE, ISO, IEC certificates and SGS test report for battery.
CSPOWER Battery Tech Co.,Ltd supply our customers reliable products with high quality and competitive price, since we have our own Lead mine & smelter factory & plate factory & SLA battery assembling factory, the purity quotient of our lead is99.998%.
CSPOWER Battery Tech Co.,Ltd manufacturer 2V/6V/12V Solar GEL battery, AGM sealed free maintenance lead acid battery, Solar deep cycle battery upto 2V3500Ah, 6V420Ah, 12V300Ah, total over 400models, mainly used for solar power, wind power, ups system, inverter system, telecom, golf cart, electric vehicles and so on.
Welcome to contact us for the battery details.
Contact CSPOWER Details:
Tel: 0086-755-29123661
Web: www.csbattery.net
www.csagmbattery.com
www.cssolarbattery.com
www.cspowerinverter.com
http://cspower.en.made-in-china.com/
| Model NO. | Nominal
Voltage
(V) | Rated Capacity(AH) 20hrs/25 | Approx. Weight | Dimensions(mm) | Terminal Type |
| kg | lbs | Length | Width | Height | Total Height |
| mm | inch | mm | inch | mm | inch | mm | inch |
| CL2-50 | 2 | 50 | 2.9 | 6.38 | 160 | 6.30 | 49 | 1.93 | 166 | 6.54 | 176 | 6.93 | T12 |
| CL2-100 | 2 | 100 | 5.6 | 12.32 | 171 | 6.73 | 71 | 2.80 | 207 | 8.15 | 227 | 8.94 | T6 |
| CL2-150 | 2 | 150 | 8 | 17.60 | 172 | 6.77 | 102 | 4.02 | 207 | 8.15 | 227 | 8.94 | T6 |
| CL2-200 | 2 | 200 | 13.5 | 29.70 | 172 | 6.77 | 111 | 4.37 | 329 | 12.95 | 356 | 14.02 | T20 |
| CL2-300 | 2 | 300 | 18.8 | 41.36 | 171 | 6.73 | 151 | 5.94 | 330 | 12.99 | 366 | 14.41 | T20 |
| CL2-400 | 2 | 400 | 26.7 | 58.74 | 210 | 8.27 | 176 | 6.93 | 329 | 12.95 | 366 | 14.41 | T20 |
| CL2-500 | 2 | 500 | 31 | 68.20 | 241 | 9.49 | 172 | 6.77 | 331 | 13.03 | 366 | 14.41 | T20 |
| CL2-600 | 2 | 600 | 38 | 83.60 | 301 | 11.85 | 175 | 6.89 | 331 | 13.03 | 366 | 14.41 | T20 |
| CL2-800 | 2 | 800 | 53 | 116.60 | 410 | 16.14 | 175 | 6.89 | 330 | 12.99 | 365 | 14.37 | T20 |
| CL2-1000 | 2 | 1000 | 63 | 138.60 | 475 | 18.70 | 175 | 6.89 | 330 | 12.99 | 356 | 14.02 | T20 |
| CL2-1200 | 2 | 1200 | 69 | 151.80 | 475 | 18.70 | 175 | 6.89 | 330 | 12.99 | 356 | 14.02 | T20 |
| CL2-1500 | 2 | 1500 | 101 | 222.20 | 401 | 15.79 | 351 | 13.82 | 342 | 13.46 | 369 | 14.53 | T20 |
| CL2-1800 | 2 | 1800 | 120 | 264.00 | 401 | 15.79 | 351 | 13.82 | 342 | 13.46 | 369 | 14.53 | T20 |
| CL2-2000 | 2 | 2000 | 132 | 290.40 | 491 | 19.33 | 351 | 13.82 | 343 | 13.50 | 369 | 14.53 | T20 |
| CL2-2500 | 2 | 2500 | 165 | 363.00 | 710 | 27.95 | 352 | 13.86 | 342 | 13.46 | 369 | 14.53 | T20 |
| CL2-3000 | 2 | 3000 | 195 | 429.00 | 710 | 27.95 | 352 | 13.86 | 342 | 13.46 | 369 | 14.53 | T20 |
