Qingdao Desiree Group Rubber Machinery Co., Ltd. >> Desiree Car Bus Truck Tire Mechanical Vulcanizing Machine

Desiree Car Bus Truck Tire Mechanical Vulcanizing Machine

Name: Desiree Car Bus Truck Tire Mechanical Vulcanizing Machine
Brand: china-manufacturer-directory.com
SKU: 689739792
Availability: InStock
Rating: 4.5 (30 reviews)

Supplier:	Qingdao Desiree Group Rubber Machinery Co., Ltd.
Price:	US $ 215000-265000/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CIF

Product Specifications

Prod Model:	LL-B1640 x 2(65.5")
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	Vulcanizing Machine
Mould Quantity:	2
Steam Dome Internal Diameter:	1640mm
Max. Closing Force:	4500X2kn
Mould Height:	254-635mm
Applicable Bead Diameter:	19''-24.5''
Main Motor Model/Power:	LG41-6/16kw
Temperature Transmitter:	Jumo
Pressure Transmitter:	Jumo
Warranty:	One Year After Commissioning
Certification:	CE, ISO

Product Description

Desiree Car Bus Truck Tire Mechanical Vulcanizing Machine / Tire Curing Press

Function:
1. For curing of all-steel heavy-duty radial tires.

2. For curing of semi-radial passenger car/light truck tires.

3. For curing of nylon bias tires with one set of additional post cure inflator.

Features:
1. The machine is multi-link type.

2. Mainly consists of main machine, center mechanism, mechanic claw, steam dome, segmented mould controller, tire stripping machine, unloader, cooling roll way, driving water piping, steam piping, force measure device, lubricating system, electrical control syetem, compressed air piping, safety device, top link centering device, etc...

3. Center mechanism type: B type.

4. Top link moving type: Two kinds, sliding back and tilting back

FOR PIPING, WE CAN DESIGN AS PER YOUR REQUIREMENTS.

Advantages:
1. High running stability.
2. Long using life with suitable maintance.

Our Services:
1. One year warranty after commissioning, and lifetime technical support.
2. Engineers available to service machinery overseas.
3. Any demand, we will give feedback within 24hours.

FAQ:
Payment:
1. T/T 30% deposit, balance before shipment.
2. Negotiable.

Contacts:
Telephone & Fax: 86-532-84130227
Mobile Phone: 18560603872

Any question, please feel free to contact with me.
Welcome to make a field inspection of our factory.

Model No.	LL-B1525×2 (63.5")	LL-B1640×2 (65.5")	LL-B1310×2 (55")	LL-B1220×2 (48")	LL-B1145×2 (45")	LL-B1050×2 (42")
Steam dome specifiction(mm)	1525	1640	1310	1220	1145	1050
Max mould closing force (kN)	4220	4500	2890	1920	1720	1320
Mould height(mm)	254-635	254-635	245-445	305-505	230-455	180-300
Main motor power(kW)	16	16	13	11	11	11
Apply bead specification	19''-24''	19''-24.5''	16''-20''	13''-20''	12''-17.5''	12''-16''
Notes	Works for the vulcanization of TBR , PCR tires or bias tires.
	If it works for curing the bias tires, the press will match with post curing inflator.
	If works for curing the radial tires, the press will match with segmented mould controller.

About us:
Qingdao Desiree Group Rubber Machinery Co., Ltd is one of the major companies of Qingdao Desiree Group, which devotes itself to designing and manufacturing of Tire curing press, Tire building machine, Dynamic balancing machine, Platen press line, Rubber mixing machine and batch off.
The Group is composed of 5 subsidiaries which are Qingdao Desiree Group Surface Treatment Equipment Co., Ltd, Qingdao Desiree Group Rubber Machinery Co., Ltd, Qingdao Desiree Group Automobile Inspection Device Co., Ltd, Qingdao Desiree Group High-rise Parking Equipment Co., Ltd and Qingdao Desiree Group Real Estate Co., Ltd. After decades of development, Qingdao Desiree Group now is Qingdao TOP 15 large-scale private enterprise.
Qingdao Desiree Group Rubber Machinery Co., Ltd established a powerful technical center in the very beginning, and has multi cooperations with more than 10 scientific research institutes and universities. By absorbing the advanced rubber machinery technology and the company's innovation, our products are now rated as the advanced level both at home and aboard.
We have a team of skilled and experienced senior engineers and technicians. We have developed several proprietary technologies which fill up the vacancy of our country. Our products achieve world class quality standards.
Group has continuously increased the input in basic equipment. Till now, our company has built modern processing workshop, metal working workshop, electric workshop and assembly workshop, and introduced a number of large modern and high-precision machining equipments to guarantee our products quality.
Carrying on the past and opening a way for future, with high quality and considerate services, our company will continuously provide our best products and service under the leadership of chairman Mr. Yang tongde. Building up into a world-class rubber machinery enterprise is our ultimate goal.
