Shanghai Stone Diesel Engine Co., Ltd. >> Deutz MWM TBD604BL6 Marine Engine

Deutz MWM TBD604BL6 Marine Engine

Name: Deutz MWM TBD604BL6 Marine Engine
Brand: china-manufacturer-directory.com
SKU: 662823362
Availability: InStock
Rating: 4.3 (145 reviews)

Supplier:	Shanghai Stone Diesel Engine Co., Ltd.
Price:	Negotiable
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB

Product Specifications

Type:	Commercial Vessels
Material:	Iron and Steel
Marine Parts:	Engine/Motor
Engine Type:	Inboard
Usage:	Trade
Engine:	4 Stroke

Product Description

Deutz MWM TBD604BL6 Marine Engine

Application		Running work			Intermission work					fuel comssumtion(MCFN) /
		Working ship			High speed ship		yacht\high speed duty ship			average compression
Condition		air/turbocharge cooled/atmospheric pressure/relative humidity: 450.1MPa/60%
Power symbol		MCFN						MFN
		(A)			(B)			(C)	(D)	g/kw. H/MPa
Speed	r/min	1500	1650	1800	1500	1650	1800	1860	1860	1500	1650	1800
TBD620V8	rated power(KW)	829	870	920	915	960	1016	1120	1168	193/1.87	196/1.79	199/1.73
TBD620V12		1240	1304	1380	1370	1440	1524	1680	1752	189/1.87	192/1.79	195/1.73
TBD620V16		1658	1740	1840	1830	1920	2032	2240	2336	194/1.87	197/1.79	202/1.73
Oil consumption		& le; 1g/kw. H
Application		Running work			Intermission work					fuel comssumtion(MCFN) /
		Working ship			High speed ship		yacht\high speed duty ship			average compression
Condition		air/turbocharge cooled/atmospheric pressure/relative humidity: 450.1MPa/60%
Power symbol		MCFN			MCFN	MXN	MC15N	MOFN	MOFN	g/kW. H/MPa
						2h/12h		2h/12h	0.5h/6h
Speed	r/min	1500	1800	2100	2200	2265	2200	2265	2300	1500	1800	2100
TBD234V6	rated power	186	222	242	302	332	302	332	347	198/1.38	210/1.37	206/128
TBD234V8		249	296	323	405	445	405	445	465	195/1.38	198/1.37	201/1.28
TBD234V12		373	444	485	605	605	605	665	695	196/1.38	198/1.37	203/1.28
TD234V6		116	132	-	-	-	-	-	-	210/0.85	213/0.82	-
TD234V8		160	186	-	-	-	-	-	-	210/0.85	213/0.82	-

TBD604BL6
Application		continues duty
		passenger ship/work boats						power station/pump set
Power code		MCFN						MCXN 1h/12h
Ambient condition		air/turbocharge cooled/atmospheric pressure/relative humidity: 450.1MPa/60%
Rated speed	r/min	1200	1350	1500		1650	1800		1200		1500		1800
Rated speed	KW	372	412	450	530	586	540	637	372	480	450	550	540	600
Mean effective pressure	MPa	1.4	1.38	1.36	1.6	1.6	1.36	1.6	1.4	1.81	1.36	1.66	1.36	1.51
Fuel consumption	g. KW. H	195	197	192	193	193	202	200	195	190	197	191	202	200
Lub. Oil cosumption	& le; 1g/kw. H
Main technical Data
