Di Water System Used UV Lamp Decrease The Bacteria

Name: Di Water System Used UV Lamp Decrease The Bacteria
Brand: China-Manufacturer-Directory.com
SKU: 739156775
Availability: InStock
Rating: 4.4 (75 reviews)

Supplier:	Shanghai Hitech Instruments Co., Ltd.
Price:	US $ 2610/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CIF,CPT

Product Specifications

Prod Model:	Master-Q plus UT
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Flow Rate:	30liter/Hour*
Instant Flow Rate:	>1.5litres/Min(Need Pressure Storage Tank)
Resistivity:	16-18.2megohm-Cm
Heavy Metal Ion(Ppb):	<0.1ppb
Toc:	<30ppb
Bacteria:	<1cfu/Ml
Granular(>0.22um):	<1/Ml
RO Water TDS(Ppm):	<10*
Dimension:	Lxwxh:50X36X54cm/ About22kg
Electrical Requirements:	110-220V,50-60Hz/300W
Type:	Separation Type

Product Description

1)Application
Feed for ultra-pure water sytem, Media preparation, Fine chemical industry, Preparation of chemical solutions used
With totrators, Buffer preparation, ion chromatography Photographic flush, Test chamber, meteorological laboratory
Equipment, Hydrogen generator, humidifier etc.

2)Flow Schematic PF+KDF+AC+RO+AC+DI+UV+TF
LV. 1 5μ M spun fiber filter
LV. 2 Mixed KDF filter
LV. 3 Granular active carbon filter
LV. 4 100GPD RO membrane
LV. 5 Post active carbon filter
LV. 6 Mixed bed resin cartridge
LV. 7 254nmUV lamp
LV. 8 0.2μ M terminal filter

3)After-sales
· The products customers buy from our company enjoy repair service since the day of purchase. In on year from the purchasing day, our company is obliged to replace components free of charge due to non-human-behavior factors except:
(1). Damage caused by maloperation or use in abnormal situations.
(2). Disassembly any part of the machine or human-behavior damage.
(3). Not repaired by our serviceman.

As a rich experience of pure water system manufacturer, Hitech uphold the common development concept with customers, and provide professional pre-sales support and after-sales service. We promise:
12months for maintenance(except consumables).
On site installation supervision.
Free system update service.
Periodically return service.
Service hotline-400.
4)Main Market
Asia, The Middle East, Eastern Europe and South Africa

n Master-Q series deionized pure water system(Tap water inlet)
Model		Deionized water purification system
		Master-Q	Master-QUT	Master-Q plus	Master-Q plus UT
Flow procedure		PF+KDF+AC+RO+AC+DI	PF+KDF+AC+RO + UV+AC + DI +TF	PF+KDF+AC+RO+AC+DI	PF+KDF+AC+RO + UV+AC + DI +TF
Application		Ware washing, Agricultural expe, General biological expe, Aquatic products feeding, Inlet water for Ultra pure water machine, Inlet water for sterilizer/T&H chamber, Buffer disposing, Aseptic drinking water, Physical and chemical analysis, Fine chemistry industry, Inlet water for Ultra pure water machine, GC/HPLC, Pharmacy research, Medicine examining
DI water quality	Resistivity	16-18.2MΩ.cm
	Heavy metal ions	0.1ppb
	TOC	30 ppb
	Bacteria	-	1CFU/ml	-	1CFU/ml
	Particle(>0.22μm)	-	1/ml	-	1/ml
RO water quality		< TDS(ppm, mg/l) of tap water×5%
Technical specification	Output(25 ºC )	15 Liters/hour*		30 Liters/hour
	Flow rate	2 Lliters/min(with pressure tank)
	Pure water outlet	RO water, deionized water
	Dimension/weight	Length×Width×Height:50×36×54cm / 20-30Kg
	Electric requirements	AC110-220V,50/60Hz,120W
Control system	Mode display	Power on, program, inlet rinse, producing, full, circle, regular outlet, disinfection, consumables replacing remind
	Safety	Low pressure and full water alarm, password, auto-reset, outlet forbidden when alarm or disinfection
	System monitor	Display quality of feed water, RO water and ultrapure water, temperature, used and left time of consumables
Feed water requirements		Tap water, inlet TDS<200 ppm,5-45ºC,1.0-4.0kgf/cm 2 (if inlet TDS>200ppm, extra pretreatment is recommended)
Purification system	Pretreatment unit	5μm spun fiber filter×1+Kinetic degradation fluxion filter×1+Granular active carbon filter×1
	RO unit	100 GPD RO membrane×1 ( Plus model: 100 GPD RO membrane×2)
	Subsequent unit	Post active carbon filter×1+Mixed bed resin cartridge×3{Plus model: Mixed bed resin cartridge×4} UT model:+254nm wavelength UV lamp cartridge×1+(0.45+0.1) μm terminal filter×1
Standard configuration		Main body(including:1 set cartridge)+4 gallon tank+ accessory box

Hitech Instruments Co., Ltd, established in 2003, specializes in manufacturing laboratory water purification systems and related apparatus. Except for the small capacity lab water purification systems, we also provide the service of large or medium-sized water treatment engineering design, complete supply, installation debugging, technical reform and technical training etc. In addition, we can provide the professional training of the lab water knowledge, and optimize the existing water purification system to help customers to reduce the cost and guarantee the stable pure water supply.

With tap water inlet, integrating various advanced water purification technologies and process control methods, our water purification systems can completely meet, even exceed, the pure water standard of ASTM, NCCLS Class I etc. It can meet the meet of advanced lab water use for different purpose. It can be widely used in the field of chemistry, biology, pharmacy, medicine, micro-electronics, semiconductor etc, meeting the application requirements of spectral analysis, chromatographic analysis, cell culture, protein purification and molecular biology.

We will constantly bring in new technology, and devote ourselves to the development of new products in order to cover diversified demands from clients. We will provide comprehensive solutions for the lab pure water with professional pre-sales support and impeccable after-sales service.

We aim to integrate products with the world market, establish first-class brand by excellent quality and gain market shares by top brand.
