Sino Age Development Technology >> Digital Brick Test Hammer Ht-75D

Digital Brick Test Hammer Ht-75D

Name: Digital Brick Test Hammer Ht-75D
Brand: china-manufacturer-directory.com
SKU: 689912982
Availability: InStock
Rating: 4.5 (46 reviews)

Supplier:	Sino Age Development Technology
Price:	Negotiable/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CIF,EXW

Product Specifications

Prod Model:	HT-75D
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Usage:	Testing Building and Bridge Construction
Impact Energy:	0.075kgm (0.735nm)
Measuring Range:	10-70n/Mm2
Storage:	Data for 4000 Concrete Structures
Dimension (Mm):	280X75X60
Net Weight:	1.1kg

Product Description

Digital Concrete Test Hammer HT-75D Details:

HT-75D is an integrated digital concrete test hammer which combines data processor and test hammer
Into one unit.
From its rebound value, the compressive strength of concrete can be calculated out automatically. All testing data can be stored in memory and transferred to PC by USB cable or wireless by Blue tooth.

KEY FEATURES:

High contrast OLED display
All setup can be made on site
Automatic calculating compressive strength
Automatic correction of impact direction
All data will be stored in memory

All data can be transferred to PC by USB cable or bluetooth(optional)
Dual display for analogue ruler and digital value

Model	HT-225D	HT-75D	HT-20D
Display	OLED digital
Measuring range	10-70N/mm2		1-25N/mm2
Accuracy	±0.1R
Impact energy	0.225kgm (2.207Nm) for testing ordinary building and bridge construction	0.075kgm (0.735Nm) for testing small and impact-sensitive parts of concrete or artificial brick	0.020kgm (0.196Nm) for testing mortar or clay of products
Communication	USB2.0 or Bluetooth(optional)
Storage	data for 4000 concrete structures
Operating temperature	-40º-60ºC
Power supply	3.7V Li-ion rechargeable battery charged via USB port
Dimension (mm)	280x75x60
Net weight	1.1kg
