Digital Platform Scale

Product Specifications

Prod Model:	TCS
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Capacity:	0.5ton~10 Ton
Size:	0.8*0.8m~2.0*3.0m
Indicator:	Have
Printer:	Have
Accuracy:	0.1kg
Weighing:	>300kg
Display Type:	LED
Material:	Carbon Steel
Measure Method:	Automatic
Application:	Industrial Scales
Function:	Weighing Scale

Product Description

Electronic floor scale features
Designed with double-layer scale
High-performance cushion shack absorber device
The unique limit device to prevent partial set
The overall framework,mobile conveniently
Wired and wireless connectivity options
Connection weighing management software and remote monitoring capabilities


The main technical indicators
OIML III standard
Safety overload:130%
Operating temperature:-30ºC~+50ºC
Voltage:220V 50Hz

Model	Maximum weighing(kg)	Sub-scale value(kg)	Accuracy Class	Dimension(mm)(length×width)
TCS-500	500	0.5	III	600×600
TCS-1000	1000	0.5	III	1000×100
TCS-2000	2000	1	III	1200×1200
TCS-3000	3000	1	III	2000×1500
TCS-5000	5000	2	III	2000×2000
TCS-10000	10000	5	III	2000×3000
