Product Specifications
| Prod Model: |
M8600 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Task: |
Program |
| Mathematical Model: |
Linear |
| Signal: |
Continuous |
| Function: |
Automatic Control |
| Condition: |
New |
| Customized: |
Customized |
| Material: |
Aluminum Alloy |
Product Description
Product features:
n The touch type high-efficient flow of key operation programming, LCD display Chinese, traditional Chinese, English three language menu arbitrary switching, graphical user interface and the text with multi-level menu operation mode.
n The new programming model, is provided with a spring, summer, autumn and winter four sets of timing scheme, each timing scheme has 99 point in time, by week repeated operation. Each time point can control the source selection, internal MP3, external audio source, 4 timing schemes can easily switch.
n In the built-in MP3 audio programming timing play, using U disk or SD card storage MP3 music, WMA, MP3 and other audio format support, can be infinitely extended storage capacity; a shortcut key, a key call MP3 tracks, a simple and convenient.
n The host comes with 2 into 6 power partition and programming automatically or manually partitioned broadcasting, to break the traditional mode of operation, opened at random channel partitioning.
n The built-in audio output monitoring function, and can adjust the monitor volume.
n The road has 2 programmable timing control power socket, manual / automatic operation. And an extended interface with external power source.
n The fire signal trigger, the host power supply automatic power on, open automatically, alarm reset all partitions, transferred to normal broadcasting.
n The automatic power failure protection, all editing program contents are not lost, automatic recovery operation calls.
n The computer of the host programming, preparation, and then downloaded to the host, the tedious manual programming becomes simple and convenient.
n The remote control, preset 18 programmable buttons, customizable key open / closed source selection, select the partition. Achieve power management, partition control, MP3 playback and other functions, remote control distance (open space) up to 1000 meters. (optional).
n The host support offline operation.
n The time to update the host computer, the host computer time synchronization with time.
Specification:
| Model | M 8600 |
| Power Supply | ~220V/50Hz |
| Consumption | 30W |
| Mp3 Frequency Response | 20Hz-20KHz/±1dB |
| Mp3 SNR | 95dB |
| Audio Distortion Degree | 0.1% |
| Radio Frequency Range | FM:87.5MHz-108MHz |
| Communication Speed | 4800bps |
| Standard Communication Protocol | Rs-422 |
| Standard Communication Interface | Rj45 |
| Alarm Input Level | Short circuit(0V) |
| Output Power | Total power :3.5KW,Single power :3KW |
| Dimension | 484x340x88mm |
| Weight | 4.50Kg |
| Material | Black aluminum panels, SPCC cold rolled sheet material chassis |
Our company is located in Foshan. Modio wide range of branded products, variety, mainly in the following; Public Broadcasting equipment: Digital IP Public Broadcasting System network, CNC public broadcasting systems, automated public address system, radio amplifier; Yang Speaker: Ceiling speakers, wall speakers, horn speakers, directional speakers, ceiling speakers, sound column Speaker, lawn speaker; Accessories: Volume control, radio microphones, UHF FM segment LCD can be no Line microphone, podium, broadcast dedicated speaker cable, assembled cabinets.
