DMB-9600 Any-to-Any Transcoder

Product Specifications

Prod Model:	DMB-9600
Markets:	North America,South America,Eastern Europe,Southeast Asia,Mid East,Eastern Asia,Western Europe
Function:	Any to Any Transcoding

Product Description

DMB-9600 Any-to-Any Transcoder

Overview
The professional DMB-9600 Any-to-Any transcoder is designed to multiple programs transcoding, supporting not only the bidirectional transcoding within H. 264-MPEG-2 formats but also down-conversion from HD programs to the SD programs. Adopting the full-duple* GE interface, DMB-9600 enables to receive 8*TSoIP transport stream and 6*DVB-ASI or 6*Tuner (DVB-C/T/ISDB-T/ATSC optional). After professional transcoding and processing of re-multiple*ing module, DMB-9600 can also output 1*MPTS or 8*SPTS through IP channel and 1*MPTS or 1*SPTS mirror transport stream of IP channel through DVB-ASI connector. Provided with unrivaled capability of transport stream re-multiple*ing, DMB-9600 can control transport bit rate real-timely and efficiently in order to improve performance and optimize video quality, and also addresses the ever-increasing needs of high quality video transcoding for operators and services providers.

Features
Bidirectional transcoding of H. 264-MPEG-2 for video
Bidirectional transcoding of MPEG-2 Layer-2-AAC for audio
Able to transcoding ma*. 8*SD programs or 4* HD programs simultaneously
Able to transcoding ma*. 8-channel audio simultaneously
8*IP input and 6*ASI or 6*Tuner(DVB-C/T/ISDB-T/ATSC optional) input
8*SPTS or 1*MPTS over IP out, or 1*MPTS/SPTS through DVB-ASI out
GE interface (TS over IP), enabling multicast and unicast, UDP protocol
IP I/O connector adopts GE/SFP interface for backup, enabling to operation more reliably
Fle*ible and unrivaled capability of transport stream re-multiple*ing
Resolution: 1920*1080I, 1280*720P, 720*576I and 720*480I
The output bit rate mode is Constants Bit Rate (CBR); The input bit rate mode is Variable Bit Rate (VBR)( for H. 264 SD/HD) and Constants Bit Rate (CBR) (for MPEG-2 SD/HD)
Local controlled by front LCD and keyboard
Remote monitoring by web browser via Ethernet interface.

SPECIFICATIONS

INPUTS
IP input: 1*RJ45 GE connector, 1*SFP connector (backup for each other)
8*IP in, UDP protocol

DVB-ASI input: 6*BNC interface
6*DVB-ASI in

Tuner input: 6*F type, (DVB-C/T/ISDB-T/ATSC optional)
6*Tuner in and 6*loop out

VIDEO AND AUDIO TRANSCODING
Video transcoding
Resolution: 1920*1080I, 1280*720P, 720*576I and 720*480I
Transcoding: 4*MPEG-2 HD to 4*MPEG-2/H. 264 HD;
4*MPEG-2 HD to 4*MPEG-2/H. 264 SD;
8 *MPEG-2 SD to 8*MPEG-2/H. 264 SD
4*H. 264 HD to 4*MPEG2/H. 264 HD;
4*H. 264 HD to 4*MPEG2/H. 264 SD;
8*H. 264 SD to 8*MPEG2/H. 264 SD
Video I/O bit rate mode:
Input bit rate mode--VBR(for H. 264 SD/HD)
CBR(for MPEG-2 SD/HD)
Output bit rate--CBR

Audio transcoding
Sampling rate: 48kHz
Bit rate: 64Kbps ~ 384Kbps
Transcoding: MPEG-1 Layer2 to AAC (Bidirectional transcoding)

OUTPUTS
IP output: 1*RJ45 GE interface, 1*SFP interface (backup for each other)
8*SPTS/1*MPTS, UDP protocol
ASI output: 1+1*ASI backup, BNC interface.
(1*MPTS or 1*SPTS)

GENERAL OPTIONS
Controlling and monitoring
Connector: 1*RJ-45, 10/100 Base-T(NMS interface)
Remote management: HTTP WEB browser via Ethernet interface
Local control: By front LCD and keyboard
Software upgrade: Via Ethernet interface.

Physical and power
Power: AC, 90~260V, 50/60Hz
Consumption: 25W
Operating temperature: 0~50° C
