ISUZU 6M3 compress garbage truck
Our company is a special purpose vehicle manufacturer that has the capacity of self-research and development
The main products are
1. Chemical liquid tank truck
2. Fire engine truck
3. Truck mounted with crane
4. Heavy duty truck, dump truck
5. Water truck,
6. Fuel tanker,
7. Van truck, insulated truck, refrigeration truck
8. Fecal suction truck, sewage suction truck,
9. Concrete mixer truck,
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Bulk cement truck,
13. Low plate semi-trailer, oil semi-trailer, van semi-trailer, fence semi-trailer, Bulk cement transportation semi-trailer, container Semi-trailer, chemical liquid transport semi-trailer, etc more than 300 types in total.
|
Model |
VL5120 |
|
Chassis Model /Manufacturer |
DFL1120/ Dongfeng |
|
Overall Dimension |
Length×Width×Height |
8000x2470×2980mm |
|
Total Mass |
12490 Kg |
|
Rated Payload |
5000 Kg |
|
Kerb Weight |
7295 Kg |
|
The parameters of chassis |
|
Chassis Model /Manufacturer |
DFL1120 / Dongfeng |
|
Driving type |
4*2 |
|
Cab |
D530, painted with yellow color |
|
Engine |
Manufacturer : |
Dongfeng Cummins Engine Co. Ltd |
|
|
Model |
B170 33 |
|
|
Rated Power |
170 HP |
|
|
Maximum power /
rotate speed: |
125(KW) /2500(rpm) |
|
|
Fuel type |
Diesel oil |
|
|
Type: |
straight six-cylinder, Intercooling, internal EGR, mechanical injection pump |
|
|
Max. torque /
rotate speed: |
670(N.m) /1300-1500(rpm) |
|
|
Displacement |
5900 ML |
|
|
Emission standard |
Euro3 |
|
Gear-box |
Model |
DF6S750 |
|
|
Manufacturer |
Dongfeng Motor Co., Ltd. |
|
|
Six forward and one reverse |
|
Clutch |
Φ395mm Diaphragm spring clutch |
|
Front axle |
4000Kg front axle |
|
Rear axle |
8490Kg rear axle |
|
Wheel base |
4700mm |
|
The number of leaf spring |
7/9+6, 8/10+8 |
|
Tyre |
10.00R20(high-performance tyres) |
|
The number of tyre |
6+1(spare tyre) |
|
A/C Air Conditioning |
With Air Conditioning |
|
Max Speed |
90Km/h |
HUBEI VELDLION MACHINERY Co., Ltd, is a high-tech enterprise approved by the Chinese government, specializing in the production of a variety of special-purpose vehicles. Our company possess legal import and export license and occupy large scales of foreign markets. The main productions of our company include more than 100 types of trucks, such as: Sprinkler Truck, Fecal suction truck, Garbage truck, Refuse compactor, Sewage suction truck, Fuel tank, High-altitude operation truck, Truck with crane, Dump truck, Instructional truck, Van truck, Semi-trailer, Fire engine, Spares, Refrigerator truck, Water wagon, Tractor, High-altitude water truck, Bulk cement truck, Chemical liquid truck, Concrete mixer truck, ect.
Our company VELDLION has strong technical force, professional QC process, advanced production equipment, stable product quality, and flexible operation modes. What's more, Production lines has roundly passed the ISO9001-2000 quality management system certification and the 3C(China Compulsory Certification).
Good quality and business reputation is guarantee of our success. We will do as we can that treating customers honestly, managing flexibly, guaranteeing high quality but low price, and keeping high efficiency.
We promise that all our products, will enjoy one year quality guarantee (for repair, replacement or compensation of faulty products) and free technical services lifetime.
Look forward to cooperate with you! Let's join hands and create a better tomorrow!
