Double PE Ice Cream Paper Cup Machinery (DB-600s)
Product Specifications
Prod Model: |
DB-600S |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Mid East,Western Europe |
Process: |
Paper Machine |
Usage: |
Packing Paper Machine |
Type: |
Paper Cup Machine |
Computerized: |
Yes |
Cup Size(',Ounce): |
7 |
Required Paper: |
Single Side PE Coated Paper |
Certification: |
ISO |
Condition: |
New |
Speed: |
80-90PCS/Min |
Automation: |
Automatic |
Product Description
DEBAO-600S high speed paper cup machine have follow features: Use the double turn-plate, double order to forming paper cup. The DEBAO-600S high speed paper cup machine is an upgrade product that base on single turn-plate paper cup machine. The machine adopts open-type, interrupted division design, gear drive, longitudinal axis design. So they can reasonably distribute each part function.
The whole machine adopts Spray lubrication, thus reduce the parts abrade, and it adopts Switzerland leister heater for cup doby and bottom paper sealing; And silicon oil flow controlled by PLC& electromagnetic valve, in total two course for top curling forming, first course rotate top curling, and second that heating and forming, thus the cup forming will be more perfectly. PLC system controls the whole cup forming process. By adopting photoelectric failure-detecting system and servo control feeding, our paper cup machine's reliable performance is guaranteed, thus offering a rapid and stable operation. The machine can auto-stop working when there is a failure. Thus it can greatly improve operation safety standard and reduce labor force. Using CCD image detection system (optionally), it will detected the broken, tainted, and molding defects cups. Without manual selection, it can reduce secondary pollution.
DEBAO-600S high speed paper cup machine simplifies paper cup forming process, this machine can finish paper feeding, gluing, cup-bottom feeding, heating, knurling, cup-mouth curling, cup collecting, etc. At one step, it is specially suitable for making paper cup with a height of 50-135.
Model | DEBAO-600S high speed paper cup machine |
Weight | 4000kg |
packing specifications | 30000x1700x2250mm |
total power | Three-phase 380v,18kw |
Air supply | 0.5-0.8mpa.0.4cube/min |
Capacity | 70-90pcs/min |
Paper specification | single pe/double pe |
paper grams | 230-400g/m2 |
paper cups specifications | A:70-95mm B:50-135mmC:40-75 mmD:5-12mm |
Zhejiang New Debao Machinery Co., Ltd. Was founded in 2001, which is a professional intelligent equipment manufacturing company of intelligent paper container machines for food and beverage, integrating software development, mechanical research and development, manufacturing and marketing. Newtop people pursue the concept of high quality and technology leading, strive to create higher value for customers. By changing the working mode with intelligent paper cup machine to make the operation more and more simple.
After 20 years concentrate on research, Newtop has gained more than 100 patents and 30 software copyrights; The Enterprise has passed ISO 9001: 2015 International Quality System Certification, ISO 14001: 2015 Environmental Management System Certification, OHSAS 18001: 2007 Occupational Health and Safety Management System Certification, GB/T 29490: 2013 Intellectual Property Management System Certification, and all Products are certified by CE.
With years of effort, we have the honor to get "National High-tech Enterprises", "National Torch Plan Industrialization Demonstration Project", "Provincial Famous Export Brand", "Provincial 'Specialized, Fined, Peculiar and Innovative' Enterprise", , "Provincial Science and Technology Achievement Award", , "Provincial Patent Demonstration Enterprise", "Provincial High-tech Enterprise Research and Development Center", "Made-in-Zhejiang Certification", "Wenzhou High Growth Enterprise" and "Local Top 30 Enterprises", becoming the leading professional manufacturer of intelligent paper container machines in the industry.
Our processing equipment are equipped with world-class CNC multi-axis Turning-Milling compound, such as DMG MORI, Hardinge, Doosan, TSUGAMI, Mazak and so on. The laboratory is equipped with Zeiss 3D coordinate detector, Mitutoyo roughness measuring instrument, profilometer and other inspection equipment, to achieve the accuracy of inspection for machine parts. These ensure the overall reliability, stability of running and high precision of paper cup machines, to enable the machine to achieve world-class product standards.
The team of Newtop is lean, dedicated and full of artisanship spirit. We focus on the field of paper cup machine for 20 years, concentrate to team building and personnel skill training system, create a R&D team of hard-working; With self-transcendence, hard-working attitude, relying on the spirit of diligence and dedicated craftsmen, to achieve the New Debao people have concept of technology leading and quality first. Based on this, we proudly provide customers with five years of quality guarantee. Now we have successfully developed an intelligent high-speed paper cup forming machine + visual inspection + sleeve insert + automatic packaging intelligent production system, which is the first in the world.
We are committed to the research and development of paper cup making industry 4.0, providing customers with a comprehensive system of the best combination of the overall solution; Aiming to build intelligent unmanned workshop, information Internet of Things+, digital management system.
Our customers are all over the world, they are in North America, Europe, Middle East and Asia. They are making paper cups with the machines of Newtop, supplying to Starbucks, Coca Cola, KFC, Master Kong, Luck-in coffee, Xiang Piao Piao(Senpure) and other famous enterprises.
Newtop will continue to work diligently to build the world's first-class intelligent paper cup machinery. We will never forget why we started and we will never change. We only do one thing: To make the smart equipment perfect! You will love it when you use it, Newtop Intelligent Paper Cup Machine, the work is so simple!
