Product Specifications
| Prod Model: |
AUTO-KX |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand: |
Autostrong |
| OEM/ODM: |
Acceptable |
| Market: |
All Over The World |
| Use: |
Deformation Testing Machine |
| Control Temperature Range: |
Rt+10~300 |
| Warranty: |
1 Year |
| MOQ: |
1 Piece |
| Certificate: |
ISO CE RoHS |
| Delivery: |
in Stock |
| Type: |
Heating Type |
Product Description
Drying Oven (AUTO-KX)
Applications:Precision drying oven is used to temperature humidity test of electrician materials, household appliances, automobiles, motorcycles, chemicals, and other product components and materials.
drying oven can test the material property in high and low temperature, such as electrical, electronic products, as well as their original devices, This drying oven is mainly made according to the national standard and user-defined requirements, it simulate the environment to test proformance of material as well as other relevant characteristics of physical at low temperature or high temperature, Through testing to determine product performance whether it is still be able to meet the intended requirements.
Features:1.1 year warranty
2. ISO17025 is free offered
3. ILAC and CNAS can be offered if required
4. ISO9001, CE, ROHS, SGS certification
5. All the export products are in English data, no chinese.
6. For machines, we can offer video for customer reference
Room size
| 350*400*350
| 400 * 500 * 500
| 500 * 500 * 600
| 500 * 600 * 750
| 700 * 800 * 850
| 800 * 1000*
1000
| 1000 *1000 * 1000
|
Dimensions(D * W * H)
| 820*860*1350
| 900*960*1450
| 1000*960*1450
| 1000*1060*1710
| 1200*1260*1810
| 1300*1460*
1960
| 1500*1460*
1960
|
Temperature Range
| A: -20 °C ~ 150 °C B: -40 °C ~ 150 °C C: -60 °C ~ 150 °C D: -70 °C ~ 150 °C
|
Humidity range
| 20 ~ 98% R.H
|
Fluctuations uniformity
| ± 0.5 °C / ± 2 °C
|
Heating speed
| 1.0 ~ 3.0 °C / min
|
Cooling speed
| 0.7 ~ 1.5 °C / min
|
Controller
| Single point imported AX of South Korea or Fuji instrument imported from Japan
|
Accuracy range
| Setting and indication accuracy: ± 0.1 °C temperature
|
Temperature and Humidity Sensor
| Platinum resistor PT100Ω/MV
|
Heating system
| Full independent systems, nickel-chromium alloy electric heating heaters
|
Circulation system
| Heat resistance and low noise air-conditioned motor, multi-blade centrifugal wind wheel
|
Inner material of chamber
| Quality carbon steel plate, phosphide electrostatic spray processing
|
External material of chamber
| SUS304 stainless steel quality mirror board
|
Insulation material
| Polyurethane rigid foam / superfine glass fiber cotton
|
Standard configuration
| Glass window 1 set, sample frame 2 pcs, test leads holes (50 or 100mm) 1 piece
|
| Security | Leakage, short circuit, over-temperature, overheating, compressor overpressure, overload, over-current protection
|
Supply Voltage
| AC380V ± 10% 50 ± 0.5Hz three-phase four-wires
|
1) - 10+ years testing equipment manufacturer;
2) - ISO9001, SGS, TUV, CE, RoHS certificated manufacturer;
3) - One Stop testing solution provider;
4) - Provide ISO17025, CE, CNAS, ILAC calibration certificates;
5) - Large quantity tester in stock with very short lead time;
AUTOSTRONG is a professional manufacturer of Industrial test equipments for products safety application with headquarter in Kowloon Hong Kong and branch factory in SHEN ZHEN city.SHEN ZHEN Branch factory is over 2600 area, it besides SHEN ZHEN airport with very convenient transportation.
AUTOSTRONG is a reputed manufacturer of Laboratory safety test equipments and has engaged in Research & Development and Manufacture test equipments for many years.More, it is one of the listed suppliers with IECEE (International Electro technical Commission) and have gained ISO9001:2008 Certification and SGS audited supplier certificate.
AUTOSTRONG has undertaken projects of national 863 program and local governmental key science &technology programs for many times.We own a Professional and International Team with more than 60 engineers form Germany, Hong Kong.All our products are strictly designed and manufactured in accordance with IEC, CE, EN, UL, VDE, ASTM, ISO and other international standards.We offer normally ex stock and also provide customized service.
We focus on provide the highest grade products and services to our clients.With almost ten years development, We are being the fastest growing manufacturer supplier of test equipments for many industrial and manufacturing scenarios and AUTOSTRONG is the safety testing equipments leader manufacturer in China.
