Product Specifications
| Prod Model: |
DT3266A DT3266B DT3266C DT3266D DT3266E DT3266F DT |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Function Range Accuracy
DC voltage 400m-4-40-400-600V ±1.0%
AC voltage 400m-4-40-400-600V ±1.2%
DCA 40m-400mA ±1.5%
ACA 40m-400mA ±1.5%
CAP 40n-100nF ±4.5%
OHM 400-4K-40K-400K-4M-40MΩ ±1.0%
ACA(CLAMP) 400-600A ±2.0%
Frequency 10Hz~10MHz ±0.5%
Frequency(CLAMP) 10Hz~10KHz ±1.0%
Power supply (AAA) 1.5V×2
Max display 3999
Data hold YES
Weight 160g
Dimension 160L×55W×22Hmm
Accessories operation manual, test leads
| Function | Range | Accuracy |
| DC voltage | 400m-4-40-400-600V | ±1.0% |
| AC voltage | 400m-4-40-400-600V | ±1.2% |
| DCA | 40m-400mA | ±1.5% |
| ACA | 40m-400mA | ±1.5% |
| CAP | 40n-100nF | ±4.5% |
| OHM | 400-4K-40K-400K-4M-40MΩ | ±1.0% |
| ACA(CLAMP) | 400-600A | ±2.0% |
| Frequency | 10Hz~10MHz | ±0.5% |
| Frequency(CLAMP) | 10Hz~10KHz | ±1.0% |
| Power supply | (AAA) 1.5V×2 |
| Max display | 3999 |
| Data hold | YES |
| Weight | 160g |
| Dimension | 160L×55W×22Hmm |
| Accessories | operation manual, test leads |
Zhangzhou Weihua Electronic Co., Ltd., is specialized in developing and producing electronic instruments. Our factory is located in Jinfeng Industrial Zone, Zhangzhou, China. We are striving to provide products with higher quality and cheaper price to our customers. With an efficient management team, we are able to provide prompt and timely delivery to our customers. The delivery time of most orders is within 10 days upon confirmation.
We have digital multimeters, digital clamp meter, capacitance meter and other digital meters. All our products are designed according to worldwide safety standards, most of our products have obtained CE approval. Our products are ideal instrument for using in the following field, laboratory, workshop, hobby, home and DIY funs user. And they are sold well at home and abroad. And we have been highly trusted and praised by our clients. We have been in business with customers from over 30 countries all over the word. We have been in business with customers from over 30 countries all over the word.
We had obtained the ISO9000: 2000 quality cortrol system certification, most of our products had gained the cetification of conformity in March of 2005, besides we have gained the quality licence for eligible export commodity in 2001.
Welcome all kinds of OEM or ODM cooperation. With the idea of being honest and keeping improving, we'd like to develop the techonology of measuring instruments with our old and new friends.
