Dual 2 SIM card GPS tracker & tracking device for truck in muti-state trip remote monitoring solution
GP5000 is a tracking of fleet and mobile asset management system product which could meet the mainstream requirements of clients.The whole system is stable and reliable after 5 years real operation and service. The general functions are as below: 1. Real time vehicle online location tracking 2. Vehicle dynamic datas and status real time monitoring 3. Vehicle driving track replay 4. Route control & management 5.Real time fuel consumption monitoring; 6. Geo-fence
Product Specification
Mechanical & Environmental |
Dimensions(L x W x H) | 103X71X26mm |
Weight | 750g (including Standard Accessories) |
Housing | Aluminum case |
Operational Temperature | -25~70 |
Storage temperature | -40~80 |
5 switch outputs | <500mA |
6 switch inputs | (4 high level trigger) (2 low level trigger) |
1 analog input | 0~5V |
1 pulse input | <3.8V (trigger) |
SMS LCD screen 2 voice communication | Optional |
Power Consumption | 60mA~100mA |
Backup Power | 8.4V 400mAh Ni-MH battery |
Input Voltage | 10~30V |
GPS Receiver |
Chipset | SiRF Star III |
Frequency | L1,1575.42 MHz |
Code | C/A Code |
Protocol | NMEA 0183 V2.2 |
Default: GGA,GSA,GSV,RMC |
Support: VTG,GLL,ZDA |
SiRF binary and NMEA Command |
Available Baud Rate | 4,800 to 57,600 bps adjustable |
Channels | 20 |
Flash | 4Mbit |
Sensitivity | Tracking: -159dBm |
Cold Start | 42seconds, average |
Warm Start | 38seconds, average |
Hot Start | 1 seconds, average |
Reacquisition | 0.1 seconds, average |
Accuracy | Position: 10meters, 2D RMS |
5meters, 2D RMS,WAAS enabled |
Velocity: 0.1 m/s |
Time: 1us synchronized to GPS time |
Maximum Altitude | < 18,000 meter |
Maximum Velocity | <515 meter/second |
Maximum Acceleration | <4G |
Update Rate | 1 Hz |
DGPS | WAAS,EGNOS,MSAS |
Datum | WGS-84 |
Function Introduction |
Type | Description |
Transmission Mode | TCP/UDP/SMS |
Data flow control/Power Saving mode | Time interval/Distance interval |
Management time of uploading | Time Reference/ Day reference/Week Reference |
Alarm kinds | GPRS/SMS/Email |
Basic Function | GPS/Electronic Mileage statistics |
Remotely listen-in |
Geo-fence(64) |
Hot spot(64) |
Domain name supporting |
Blind area data supplementary uploading |
History data storage (43200 pcs) |
GPS antenna open/ short detection |
Automatic self-check/recovery/protection |
Build-in backup battery |
Alarm Function | Geo-fence: enter Geo-fence/ exiting Geo-fence |
Overtime parking |
GSM module restart |
Fatigue driving |
Over speed |
Panic button (SOS) |
Backup battery starting |
Illegal door-opening |
Illegal ignition |
Fuel level change |
Extended fuel level change |
Seat belt unfasten |
Harsh braking |
Vehicle sliding in neutral gear |
Hot Spot enter/exit |
Tow |
Deviation from the route |
Over speed driving on the road or area |
Over speed driving on the road or area |
Support External Device | Dispatch Screen |
Fuel Sensor(Analog) |
CCD Camera |
RFID Device |
Password Keypad |
Bar-Code Scanner |
Temperature Sensor |
Control Function | Cutting off the Fuel pump of vehicle |
Management Function | Alarm Report |
Day Mileage Report |
Trip Report |
Parking Report |
Idling Report |
Seat Belt unfasten Report |
Harsh Braking Report |
Vehicle sliding in neutral gear Report |
I/O Port | Switch signal inputs(6) |
Switch signal output(5) |
Analog signal input(1) |
Analog signal input(1) |
Analog signal input(1) |
