Shandong Yanggu Hengtai Industrial Co., Ltd. >> Dwv PVC Pipes and Fittings 125mm UPVC Pipe for Water Supplying

Dwv PVC Pipes and Fittings 125mm UPVC Pipe for Water Supplying

Name: Dwv PVC Pipes and Fittings 125mm UPVC Pipe for Water Supplying
Brand: china-manufacturer-directory.com
SKU: 728304145
Availability: InStock
Rating: 4.8 (117 reviews)

Supplier:	Shandong Yanggu Hengtai Industrial Co., Ltd.
Price:	US $ 4.15/Meter
Min Order:	2000/Meter
Quantity::
Trade Terms:	FOB,CFR,CIF

Product Specifications

Prod Model:	UPVC125
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Wall Thickness:	4.8mm
Pressure Rating:	0.63mpa,0.8mpa,1.0mpa,1.25mpa
Length:	10m, 12m or Customized Length
Color:	White, Grey or Customized Color
Form Supplied:	Plain End Type, Bell End Type, Socket Spigot Type
Standard&Certificates:	ISO4422:1996, ISO9001, ISO14001, Ohsas18001
Material:	PVC

Product Description

Professional Large Manufactuer Of PVC Pipe With Actual Factory In Shandong Prov.
Produce UPVC/MPVCpipe With Large Diameter upto dn630mm
Sevice since 1998
Annual Production Capacity Upto 200, 0000 meters/Month

Rigid PVC-U/PVC-M water pipe
1. Material: Unplasticized Poly (Vinyl Chloride)
2. Pressure Rating: 0.63Mpa, 0.8Mpa, 1.0Mpa, 1.25Mpa, 1.6Mpa, 2.0Mpa,
3. Size: Full 20mm through 630mm availability
4. Colors: Gray, white or other colors availability upon request
5. Form Supplied: Plain end pipe, bell end pipe or gasketed pipe with 4m, 5.6m, 5.8m or other length availability upon request

6. Main Features:
1) Light weight, nice figure.
2) Acidproof, alkaliproof, pressureproof.
3) Easy to load and unload.
4) High flow capacity, endurable, nontoxic.
5) Good resistance to water pressure and good electric insulation.
6) Standard: ISO4422-2-1996 and CJT272-2008

Main Applications:
Municipal water supply
Commercial & Residential water supply
Garden, farm, agriculture irrigation
Industrial liquids transportation
Sewage treatment

Advantages
1. High Flow Capacity: The smooth interior walls and low friction of PVC water pipe result in low resistance and high volume.
2. Corrosion Resistant: PVC water pipe is non-conductors of electricity and immune to electrochemical reaction caused by acids, bases, and salts that cause corrosion in metals.
3. Low installation costs: PVC water pipe is lightweight and is installed with solvent cement, thread, flange, and gasketed joint. Ease of installation reduces the installation costs.
4. Longevity: PVC water pipe can work for more than 50 years under proper use.
5. Environment-friendly: PVC water pipe can be recycled.

Applications
1. Soil and waste discharge pipelines (low and high temperature) inside buildings
2. Rainwater pipelines inside the building
3. Farm, garden or agriculture irrigation
4. Buried drainage pipelines without pressure on the ground

Properties		Typical Value
Specific Gravity, g/cm 3 (20°C)		1.35~1.55
Vicat Softening Temperature, °C		≥79
Longitudinal Reversion,% (150°C)		≤5
Dichloromethane Resistance Test, (15°C, 15min)		No attack
Failing Weight Impact Test, TIR,% (0°C)		≤10
Tensile Yield Strength, MPa		≥40
Fitness Test for Purpose of the System	Watertightness Test	No Leakage
	Airtightness Test	No Leakage

PVC-U water pipe specification catalog Executive Standard:GB/T 10002.1-2006 ISO4422-1996

dn	length	standard	en	pn
(mm)	(meter/root)	standard	(mm)	(Mpa)
20	4	ISO	1.5	1.6
20	4	GB	2	2
25	4	ISO	1.5	1.25
25	4	GB	2	1.6
32	4	ISO	1.6	1
		GB	2	1.25
		GB	2.4	1.6
40	4	ISO	1.6	0.8
		GB	2	1
			2.4	1.25
			3	1.6
50	4	ISO	1.6	0.63
		GB	2	0.8
			2.4	1
			3	1.25
63	4	ISO	1.9	0.63
		GB	2	0.63
			2.5	0.8
			3	1
	6	ISO	1.9	0.63
		GB	2	0.63
			2.5	0.8
			3	1
75	4	ISO	2.2	0.6
		GB	2.3	0.63
			2.9	0.8
			3.6	1
	6	ISO	2.2	0.6
		GB	2.3	0.63
			2.9	0.8
			3.6	1
90	4	ISO	2.7	0.6
		GB	2.8	0.63
			3.5	0.8
			4.3	1
	6	ISO	2.7	0.6
		GB	2.8	0.63
			3.5	0.8
			4.3	1
110	6	GB	2.7	0.63
			3.4	0.8
			4.2	1
125	6	GB	3.1	0.63
			3.9	0.8
			4.8	1
140	6	GB	3.5	0.63
			4.3	0.8
			5.4	1
160	6	GB	4	0.63
			4.9	0.8
			6.2	1
180	6	GB	4.4	0.63
			5.5	0.8
			6.9	1
200	6	GB	4.9	0.63
			6.2	0.8
			7.7	1
225	6	GB	5.5	0.63
			6.9	0.8
			8.6	1
250	6	GB	6.2	0.63
			7.7	0.8
			9.6	1
280	6	GB	6.9	0.63
			8.6	0.8
			10.7	1
315	6	GB	7.7	0.63
			9.7	0.8
			12.1	1
355	6	GB	8.7	0.63
			10.9	0.8
			13.6	1
400	6	GB	9.8	0.63
			12.3	0.8
			15.3	1
450	6	GB	11	0.63
			13.8	0.8
			17.2	1
500	6	GB	12.3	0.63
			15.3	0.8
			19.3	1
560	6	GB	13.7	0.63
			17.2	0.8
			21.4	1
630	6	GB	15.4	0.63
			19.3	0.8
			24.1	1
