Easy Operation and Water Saving Industrial Sewage Treatment Plant Liquid and Solid Separate Equipment Daf Dissolved Air Flotation Device

Product Specifications

Prod Model:	YW
Markets:	South America,Southeast Asia,Africa,Mid East,Eastern Asia
Certificate:	SGS;BV;ISO9001;National Patent
Material:	Carbon Steel/SUS
Color:	Silver Grey/Green/Blue/etc
Treating Capacity:	1~300m3/H
Oil And Tss Remove Rate:	More Than 85%
Cod Remove Rate:	30~50%
Method:	Combined Treatment
Usage:	Agriculture

Product Description

Easy Operation and Water Saving Industrial Sewage Treatment Plant Liquid and Solid Separate Equipment DAF Dissolved Air Flotation Device

==================================================================================



Product Description

   YW series dissolved air flotation machine is mainly for solid-liquid or liquid-liquid separation. Large sum of micro bubbles produced by dissolving and releasing system adhere to solid or liquid particles with same density as waste water to make the whole float to the surface thus achieve the aim of solid-liquid or liquid-liquid separation.

Application:
1.Separate small particles and algae in groundwater.
2.Recover valuable products in industrial sewage such as paper pulp.
3.Act as secondary sedimentation tank to separate and concentrate suspended particles and sludge.

Technical Parameters



Specification	Capacity (m3/h)	Dissolved gas water (m3/h)	Main dynamo power (kw)	Foam scraper power (kw)	Air compressor power (kw)	Dissolved air tank size (mm)	Overall dimension   (mm)
YW-5	4-5	1.5-2	3	0.55	1.5	Φ400x1000	3300x1800x2200
YW-10	8-10	2-3	4	0.55	1.5	Φ500x1512	4000x2100x2200
YW-20	15-20	5-7	7.5	0.55	1.5	Φ500x1512	4600x2400x2200
YW-30	20-30	6-10	7.5	0.55	1.5	Φ500x1512	5200x2600x2400
YW-40	30-40	8-13	7.5	0.75	2.2	Φ600x1880	6000x2600x2400
YW-50	40-50	15-20	7.5	0.75	2.2	Φ600x1880	7000x2600x2400
YW-60	50-60	18-27	11	0.75	2.2	Φ600x1880	7600x2800x2400
YW-80	70-80	24-32	11	0.75	3	Φ650x2034	9200x2800x2400
YW-100	90-100	30-35	15	0.75	4	Φ700x1980	10000x2800x2600
YW-150	125-150	60-80	22	1.1	4	Φ800x1980	13500x2800x2600
YW-200	175-200	80-100	22	1.1	5.5	Φ800x2100	15800x2800x2600
YW-250	225-250	110-120	22	1.1	5.5	Φ800x2400	15200x3400x2600
YW-300	280-300	120-180	37	1.1	5.5	Φ1000x2900	19200x3400x2800

================================================================================

Our service:

24-hour a day, 365-day a year access to a toll-free health care professional hotline for questions and trouble-shooting assistance FREELY.

all year round on site installation and debugging service abroad with professional engineer guide and training.

Professional technical support and specifit manual with drawing.

=======================================================================


FAQ
1.Q:Are you a factory or trading company
A: We are a factory, we have rich experience for manufacuring water processing equipment for more than 10 years.

2.Q:Where is your factory located? How can i visit there?
A: Our factory is located in No.3388 Zhencheng Road, Huangtu Town, Jiangyin City, Jiangsu Province,China. It is about 2 hours from Shanghai airport. We can pick you up if you need, welcome to visit our factory.

3.Q: Do you have  minimum order quantity request?
A: No minimum order, but it can get a discount if you order a large quantity.

4.Q: Do you have  certificates?
A: Yes, we have ISO,SGS certificate.

5.Q: Can you meet my special requirements for my products?
A: Yes, we have a professional design team. We can provide drawings according to your requirements.
6. Q:How to buy your idea products?
  A:You can provide us your water sources, water quality, flow rate and ground area (connect us for more details).
7. Q:How to pay?
  A: TT and L/C are acceptable and TT will be more appreciated. 30% deposit before producing, 70% balance before loading by TT.
8. Q:What is the delivery time?
  A: It depends on order quantities. Generally speaking, the delivery time will be within 4 to 6 weeks.
9. Q: How to pack the products?
  A: We use standard package. If you have special package requirements, we will pack as required, but the fees will be paid by customers.
10. Q: How to keep your equipments from corrosion?
A: We use the world-famous paint, like SigmaCoatings,PainBow,etc. What's more, we paint strictly according to the standard process.
11. Q: How do you manufacture your equipment ?
  A:Our  machining technology  includes laser/plasma cutting, automatic welding,CNC cutting and bending.

12. Q:How to install after the equipments arriving destination?
A: We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you. However, the visa fee, air tickets, accommodation, wages will be paid by buyers.
======================================================================
