Shenzhen Myled Optech Co., Ltd. >> Eazy Installation Media LED Stage Rental LED Display

Eazy Installation Media LED Stage Rental LED Display

Name: Eazy Installation Media LED Stage Rental LED Display
Brand: China-Manufacturer-Directory.com
SKU: 757764205
Availability: InStock
Rating: 4.9 (112 reviews)

Supplier:	Shenzhen Myled Optech Co., Ltd.
Price:	US $ 1-1000/Piece
Min Order:	5/Square Meter
Quantity::
Trade Terms:	FOB,CIF,EXW

Product Specifications

Prod Model:	P6, P8, P10
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Renta De Pantallas LED:	Video Pantallas LED Outdoor
Display Type:	LED Video Display
Tube Chip Color:	Full Color
IP Rating:	IP65
Pixel Configuration:	1R, 1G, 1B
Certification:	ETL
Display Function:	Video Display
Application:	Stage Performance
Scanning Mode:	Static Scan
Average Power Consumption:	220W / m²
Pixel Pitch:	6.6mm
Pixel Density:	22500

Product Description

eazy installation media LED stage rental led display

Alto brillo, 5500nit
6.6mm pixel pitch
Protection ingress, frontal IP65 & Rear IP43
640mm*640mm*77mm
El sistema de control, en 100% español
fácil de montar y desmontar

Características: Estado actual de la técnica de diseño, rápida de instalar y desmantelar
1) Delgado, ligero, fácil de instalar y de transportar, rápida de instalar y desmontar.
2)La calidad de grado superior, utilizar el mejor material original, y producir con más cuidado
3) Humanista de Patentes diseño de la estructura, de uso especial para el alquiler de colgar el uso
4)Alta resolución

Main Parameter
Category	Parameter
Pixel Pitch	6mm
Optimum Viewing Distance	6-15m
Density of Pixel	27777pixels/
Brightness	≥1800nite
Module Resolution	40*40
LED Encapsulation	SMD3528 1R1G1B
Driving Method	Real 1/8 Scan
Optimum Viewing Angle	H: 120°V:120°
Module Size	2402406(mm)
Module Power	39w
Module Weight	200g
Cabinet Size	480480101(mm)
Cabinet Resolution	80*80
Cabinet Power	155w
Cabinet Weight	8.5kg
IP Rating	Front/Rear:IP30
Refresh Rate	200-1000Hz( Different according to the different Driving IC )
Luminance Consumption	Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature25ºC.
MTBF	>5000hours
Defective Dot Rate	<0.0001
Life Span	>100000hours
Working Voltage	110-240 AC±10% 50-60Hz
Working Temperature/Humidity	0ºC- +45ºC/10-90%RH
Storage Temperature/Humidity	-10ºC - +55ºC/10- 90%RH
Input Signal	RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Connector	CAT5 Cable(Length≤1430m),Optical link( Length≤20km,Optional)
Note: The above parameter is just for reference. Changes can be made according to customers' requirements.
