Shenzhen EDUP Electronics Technology Co., Ltd. >> Edup Ep-9512n 150Mbps Portable 3G Wireless Router with SIM Card Slot (EP-9512N)

Edup Ep-9512n 150Mbps Portable 3G Wireless Router with SIM Card Slot (EP-9512N)

Edup Ep-9512n 150Mbps Portable 3G Wireless Router with SIM Card Slot (EP-9512N)
Supplier: Shenzhen EDUP Electronics Technology Co., Ltd.
Price: Negotiable/Piece
Min Order: 10/Piece
Quantity::
Trade Terms: FOB,EXW
contact supplier

Product Specifications

Prod Model: EP-9512N
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Battery: 4500amh
Type: Wireless
Firewall: Firewall
Application: SOHO
Ports: ≤4
Transfer Rate: 150mbps

Product Description

Description
The EP-9501N is a mini size portable 3G/150M wireless router integrated access point, router and firewall, share a HSDPA/EVDO mobile connection. By plug-in a HSPA/EVDO USB modem to the router, a Wi-Fi hotspot is established instantly, allowing users to share an Internet connection somewhere 3G coverage is available.
Because supports ROUTER/AP/CLIENT-3modes selection by the hardware switch and powered by battery, so it is very suitable for travel, moving and outdoor application.
The AUTO-RUN CD can help novice user setup the router step by step to complete the Internet connection, wireless network settings and security configurations.

Features
1. Supports 64/128-bit WEP, complies with 128 bit WPA standard (TKIP/AES)
2. Supports 135/121.5/108/81/54/40.5/27/13.5/65/58.5/52/39/26/ 19.5/13/6.5/54/48/36/24/18/12/9/6/11/5.5/2/1Mbps wireless LAN Data transfer rates
3. Provides Bridge(AP/Client) mode
4. Wireless speed up to 150Mbps when connected to 11n device
5. Wireless security encryption easily at a push of "WPS" button
6. Seamlessly compatible with 802.11b and 802.11g devices
7. Internal Antenna

Specification
Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Wireless Signal
Rates With
Automatic Fallback 11n: Up to 150Mbps (Dynamic)
11g: Up to 54Mbps (Dynamic)
11b: Up to 11Mbps (Dynamic)
Frequency Range 2.4-2.4835GHz
Wireless
Transmit Power 20dBm(EIRP)
Modulation Type DBPSK, DQPSK, CCK, OFDM
Receiver Sensitivity 135M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER

Wireless Security 64/128 bit WEPWPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Interface 1 10/100M WAN Ports
1 USB2.0 for UMTS/HSPA/EVDO USB Modem
Antenna Type 2dBi Internal Omni-directional Antenna
Power supply Input AC100~240V, output DC/5V/1A
Operating Temperature 0° C~40° C (32° F~104° F)
Storage Temperature -40° C~70° C (-40° F~158° F)
Relative Humidity 10% ~ 90%, non condensation
Storage Humidity 5%~95% non-condensing
Weight 110g
Dimensions: 88mm× 62mm× 18mm
Product Specification
Color White
BatteryCapacity 3500mAh/3.7V
Base Function SSID
Channel 1-13
Band 20Mhz, 40Mhz. Automatic
Working Mode Wifi AP/3G Router/Wifi Router
Transimissition Speed Up stream: 5.7Mbps, down stream: 7.2Mbps
Input Power 5V ± 5%, 0.6A
Output Power 5V ± 5%, 1A
Automatic Identification Automatic ADSL/DHCP
Wifi Repeater Wifi hotpot spread area boost wifi signal
Multimedia Surpport DLAN standard, WEB service
Standard IEEE802.11b/g/n
Transimissition Rate 150Mbps
Interface 1 10/100M Adaptive WAN / LAN port with auto-flip (Auto MDI / MDIX);
1 USB 2.0 interface; output 5V/1A, for charging for digital products
1USB 2.0 interface; Used to connect to 3G dongle
Button On/off button
Short press turn on the power
Long press turn on/off the wifi
Reset botton(press 6s then restore Factory
LED Power indication
Rj45 indication
3G instructions
BatteryIndication
Antenna Built-in Omni Antenna
Size 120*65*18mm
