Efd Series High Frequency Power Transformer with ISO9001
Product Specifications
| Prod Model: |
EFD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Environmental Certification: |
ISO14001 |
| Quality Certification: |
ISO9001 |
| Specification: |
High Permeability |
| The Number Of Needle: |
8-12 |
| Application: |
Electronic |
| Phase: |
Three |
| Coil: |
Core-type Transformer |
| Brand: |
Liwang |
Product Description
Product description of the Efd Series High Frequency Power Transformer with ISO9001 Application:
1. VCRS, Copy machine , Audio equipment , Game machines
2. TV sets, Microcomputer equipment, printers, Terminals
3. communications control equipment
4.Switching power supply, chargers, alarm system
5. UPS, VCD/DVD players, audio and visual equipment
6. OA machines, inverters, chargers, alarm system| type | The number of needle | Dimension |
| A | B | C | D | E |
| EFD-12 | 8 | 6 | 17 | 20 | 3.0 | 13.5 |
| EFD-15 | 10 | 7.3 | 18.2 | 21.35 | 2.5 | 15 |
| EFD-15 | 10 | 7.5 | 19.3 | 22.6 | 3.0 | 16.7 |
| EFD-20 | 10 | 9.4 | 25.4 | 27.7 | 3.75 | 21.7 |
| EFD-20 | 12 | 9.7 | 24 | 26.8 | 3 | 20 |
| EFD-25 | 10 | 13.4 | 29.7 | 35.4 | 5 | 25 |
| EFD-25 | 10 | 12.6 | 29.7 | 31.5 | 5 | 25 |
| EFD-30 | 12 | 12.6 | 31.6 | 35.5 | 5 | 30 |
Electrical Characteristics:
1.Operating Temperature range:-20 to +45
2.Storage temperature:-40 to 70
3.Switching frequency:1KHz to 200KHz
4.Withstanding voltage:1500/3750VAC for 1 minute between primary and secondary
5.Insulation resistance:500VDC 100MΩ miin. between primary&secondary.
Advantage:
1.Universal purpose
2.Reliable safety approvals
3.Low profile and low weight
4.Low no-load loss
5.Low mechanical hum
6.Low stray magnetic field
7.Low operating temperature
8.High efficiency
9.Competitive price
10.Easy to install
Features:
1. Custom designs available
2. High efficiency of over 95%
3. High frequency range 10kHz-1MHz
4. High isolation strength
5. Lower profile and weight
6. high power density
7. High-temperature resistant
8. Operating temperature -40°C to +125°C
9. Power range 10w-10kw
![]()
![]()
![]()
![]()
If you have any special requirement, please don't hesitate to contact us, we will make customized design to meet your needs.
