Product Specifications
| Prod Model: |
JF-L-A049 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand: |
Jinfeng |
| Material: |
Galvanized Steel |
| Uselife: |
15 Years |
| Certificates: |
ISO9001:2008 |
| Size: |
1950*350*380mm |
| Surface Treatment: |
Cold/Hot Galvanization |
| Customization: |
Accept |
| Feeding System: |
Automatic |
| Drinking System: |
Automatic |
| Manure Removal System: |
Automatic |
| Power Source: |
Electric |
| Type: |
Chicken Cage |
| Usage: |
Chicken Cage |
Product Description
Automatic layer chicken cage
1. A type and H type
2. Use: Chicken
3. Durable
4. Certified by ISO9001: 2008
Automatic Layer Chicken Cage:
Produced by Jinfeng, is certified by ISO9001: 2008. Automated controlling system, easy maintenance and operation, anti-corrosive, long durability. The advanced ventilation system, automatic feeding system, and automatic controlling system can save energy, increase efficiency and lower feed conversion ratio.
Detailed description:
1. Material: Galvanized steel wire and angle iron.
2. Surface treatment: Galvanization, it is the most advanced Automatic Galvanization Line all over the world imported from German, and also the only Automatic Galvanization Line in China.
Please check the galvanized effect below:
3. Specification:
Size for one group:
Cage size: (L*W*G) 1950*350*380mm.
Two sides (back-to-back): 1950*2150*1500mm.
4. Tiers/layers: 3 tiers. 4 and 5 tiers also available.
Please see the strong structure of the cage as follows, the worker whose Weight is 60kg standing on the cage.
5. Cage doors/group:
One side (L*W*G) 1950*400*1470mm: 5 doors/layer*3 layers*1 side=15 doors.
Two sides (L*W*G) 1950*2150*1900mm: 5 doors/layer*3 layers*2 sides=30 doors.
6. Chicken quantity/Group: 3 PCS/door * 30doors/group = 90 PCS
7. Crib material: Mainly PVC.
Crib size: 70*80*120mm /90*100*160mm. Loading Capacity of each crib: More than 60KG/PC.
8. Chicken Manure Removal Belt is imported from Italy, width is 1110mm, thickness is 1mm.
9. The automatic nipple drinkers are JINFENG Patent, stainless steel nipples, certified by ISO9001: 200
8, the Warranty is 20 years.
10. Water Split with JinFeng Patent, self-conditional equipment on the water line
11. Water pressure controlling system and water terminal equipment
|
Item No. |
/ |
JF-C01 |
|
Materials |
/ |
Q235 steel wire |
|
Surface Treatment |
/ |
Hot/cold Galvanization |
|
Tiers |
/ |
2/3/4/5 tiers by clients's option |
|
Dimensions/unit |
mm |
(L*W*H unit) 1950*350*380 |
|
Installtion Dimensions |
mm |
(L*W*H unit) 1990*2400*1900 |
|
Cells/unit |
pcs |
5(390mm/cell*5cells) |
|
Rearing Period |
weeks |
16-72 weeks |
|
Floor space/bird |
cm2 |
455 |
|
Birds/cell |
birds |
3 |
|
Bottom wire mesh angle |
/ |
9. |
|
Distance of bottom wire |
mm |
25max |
|
Sets/row |
sets |
1-55 |
