Product Specifications
| Prod Model: |
EMF8701 Series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe |
| Measuring Principle: |
Electrical Principles |
| Accuracy: |
±0.2-0.5% |
| Sensor: |
Tube/Flange |
| Size: |
Dn6~Dn500 |
| Type: |
Electromagnetic Flow Meter |
| Measuring Media: |
Liquid |
Product Description
We have kinds of flowmeters suit for different market requests.
Welcome to contact with us for more details.
Features for EMF8601 electromagnetic flowmeter:
EMF8601 electromagnetic flowmeter converter and MF01 by the E8600 sensors, switches with two-line LCD display, are a cross between the Simple EMF8100 and EMF8700 smart meter.
E8600 Converter Technical Data:
Flow in Chinese or English display 2-line LCD display, direct display to the flow and percentage of positive and negative flow, velocity and other data
Accuracy grade better than 0.5%
Parameter settings directly through the front panel buttons to set the parameters: Flow display units, the output signal range and pulse when the
Value, zero adjustment, damping time, etc.
Output
Current output 4-20mA
Active pulse frequency output: High ≥ 20V low ≤ 0.5V load current ≤ 20mA
Passive Pulse: High = external power supply-1V (external power supply voltage should be ≤ 30V) low ≤ 0.5V load
Current ≤ 50 Ma
Communication Interface RS485
Protection class IP65
Power Supply DC 24V or AC 220V
MF01 sensor technology parameters
Electrode material: Optional stainless steel 316L, Hastelloy C, Hastelloy B, titanium, tantalum, tungsten carbide, etc.
Lining Material: Optional poly-FEP (FEP), chloroprene rubber (Ne), polyurethane rubber (Po), polytetrafluoroethylene (PTFE)
Medium Temperature: -40 ~ 180 (Note: The temperature characteristics by the lining material restrictions)
Case Material: Carbon steel (also stainless steel according to customer's request)
Protection class: IP65, IP67, IP68
Connection flange: GB9119 (directly with the pipe flange HG20593-1997 and other direct connection)
