| Supplier: | U-Therm International (H. K. ) Limited |
|---|---|
| Price: | Negotiable |
| Min Order: | 1/Piece |
| Quantity:: | |
| Trade Terms: | FOB |
|
|
| Prod Model: | SET Series |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model | SET-02/SET-02L | SET-05/SET-05L | SET-10 |
| TELESCOPE | |||
| image | erect | ||
| magnification | 30X | ||
| effective aperture | 45mm | ||
| resovling power | 3” | ||
| field of view | 1° 30’ | ||
| minimum focusing distance | 1.4m | ||
| stadia ratio | 100 | ||
| stadia constant | 0 | ||
| tube length | 157mm | ||
| ANGLE MEASUREMENT | |||
| reading system | absolute encoding | ||
| diameter of circle (VHz) | 79mm | ||
| minimum reading | 1” /5” /10” selectable | 10” | |
| accuracy | 2” | 5” | 10” |
| detection method: hor. ver. | dual dual | dual dual | dual dual |
| DISPLAY | |||
| (LCD) display type | 2 sides | ||
| MEMORY | |||
| internal memory | capacity for 256 pairs of H. & V. angle | ||
| LEVEL SENSITIVITY | |||
| plate vial | 30” /2mm | ||
| circular vial | 10’ /2mm | ||
| COMPENSATION | |||
| system | liquid-electric detection | plate vial | |
| working range | ± 3’ | ||
| accuracy | 1” | ||
| OPTICAL PLUMMET | |||
| image | erect | ||
| magnification | 3X | ||
| focusing range | 0.5m ~ ∞ | ||
| field of view | 5° | ||
| PHISICAL CHARACTERISTICS | |||
| laser pointer | ET-02L: yes | ET-05L: yes | NO |
| operating temperature | -20& ordm; C ~ 45& ordm; C | ||
| internal power supply | Rechargeable Ni-H battery / AA battery | ||
| voltage | 6VDC | ||
| operating time | 10 hours | ||
| dimension | L145 X H318 X W179mm | ||
| weight | 5.2kg | ||
