Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
KOYO 9 advanced control technology
1. The advanced VVVF control system, creating the core brand
2. KOYO self-designed main board. It can store 1000 pieces error record code which is convenient for maintenance, and reduce the maintenance time.
3. RS485 remote communication is used for monitoring timely.
4. Internet remote monitor and remote parameters setting.
5. Position sensor can detect the exact lift cabin position, and then make the lift run normally according the speed diagram. It can realize stop directly and shorten the lift running time.
6. VVVF speed adjustment can calculate the vest speed diagram. It can come to the vest lift running control by the requirement of speed and load. Continuously PID control can realize the precision lift operation control.
7. ERD emergency leveling device can make the lift run to the nearest floor and open the door to release the passengers when the power failure. It makes lift more safety.
8. LED DOT matrix have good energy saving, long service lift. Before designing, we set these lights as KOYO standards. By now they have gotten good reputation from clients.
9. 32bits ARM microprocessor technology.
|
Type |
Passenger, villa, panoramic, hospital, freight, car, cargo |
|
Load(kg) |
450,630,800,1000,1350,1600,2000,2500,3000,5000 |
|
Speed(m/s) |
0.5, 1.0, 1.5, 1.75, 2.0, 2.5, 3.5, 4.0, 5.0 |
|
Most stops |
≤64 |
|
Group control |
≤8 units |
KOYO Elevator Co., Ltd., is a professional designer, researcher, manufacturer, installer and maintainer of elevator, escalator, passenger conveyor and car parking system. In 2002, KOYO established a modern production base in Kunshan city, with total investment of USD 20 million and registered capital USD 15 million. The land area is more than one hundred thousand square meters. At present KOYO holds many patents and can produce up to 8m/s speed, 8 group-controlled elevators, 25m rise height of escalators and 200m length passenger conveyor. Now, KOYO has one graduate work station and one doctoral work station.
Combined with German technology and cooperated with Suzhou University and Shanghai Jiao Tong University, KOYO has successfully researched and developed its own main board and control system, it is much more stable, safe, comfortable, economical and environmental.
Since established, KOYO products have been very popular in Germany, France, Italy, America, Indonesia, United Arab Emirates, Pakistan, Malaysia, Portugal, Ukraine, Greece, Thailand, Mexico, Bulgaria, Brazil, New Zealand, Turkey, Chile, Ireland, Colombia and South Africa etc. Sales network has reached to 72 countries.
KOYO indraughts advanced fabrication process and safe reliable control system from Germany. KOYO strictly implements European EN115 and EN81 standards, which is equivalent to China GB16899-1997 and GB7588-2003 standards. KOYO was been awarded Germany TUV Certification with CE Logo and ISO9001: 2008 certification.
The remarkable quality makes KOYO achieve glorious success. With KOYO spirit and KOYO people's effort, we have won 2010 South Africa Football World Cup project. KOYO travel with time, grow with time. With continuous effort, KOYO kept going forward and achieved another mile stone in the 21st century by winning 2011 Cricket World Cup project in Sir Lanka.
KOYO elevator ranked the third among the export enterprises published by China Foreign Economic and Trade Promotion Committee, and ranked the second among the export enterprises in China Elevator Association.
KOYO Elevator design what you wants, meet what you needs.
