Shenzhen Yilong Led Display Co., Ltd. >> Energy Saving LED Display

Energy Saving LED Display

Name: Energy Saving LED Display
Brand: China-Manufacturer-Directory.com
SKU: 725328055
Availability: InStock
Rating: 4.7 (128 reviews)

Supplier:	Shenzhen Yilong Led Display Co., Ltd.
Price:	US $ 985/Square Meter
Min Order:	1/Square Meter
Quantity::
Trade Terms:	FOB,EXW

Product Specifications

Prod Model:	P10mm
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Module Size:	160mm*160mm
Module Resolution:	16*16
Brightness:	8500CD/M2
Pixel:	1r1g1b
Module Weight:	0.75kg
Blind Spot Rate:	0.0001
Control Mode:	Synchronous Control
Driving Mode:	1/4scanning Constant-Current
Lifetime:	100000hours
Best View Distance:	10m
Tube Chip Color:	Full Color
IP Rating:	IP65
Pixel Configuration:	1R, 1G, 1B
Pixel Pitch:	10mm
Display Function:	Video Display
Scanning Mode:	1/4 Scan
Certification:	RoHS
Pixel Density:	10000 dot / m²
Average Power Consumption:	300W / m²

Product Description

TypePH10
Pixel pitch(mm)10
Pixel density(DOT/)10000
Pixel specification 1R1G1B
View degree110
Module size160mm*160mm
Module resolution(DOT * DOT)16*16
Module number / cabinetDepend on cabinet size
Grey level(level)4096
Refresh rate(Hz)>380
Brightness(CD/)≥5000
Weight(/)35
Display color(color)16777216
Visual distance(m)>10
Power(w/)Max:800
Average value:266
Drive mode1/4 scanning, Constant-current drive
Blind spot rate≤0.0003
Lifetime 50000 hours
Working voltage (V)220∨±15%
Working temperature (ºC)-20ºC~60ºC
Working humidity (RH)10%~90%RH
Control mode Synchronous control
Control systemPCTV card +DVI display card+ main control card +fiber transfer
SoftwareLED by studio or the user
Computer WINXP/WIN2000/WIN98 etc.
Display cardDVI
Control distance Twisted-pair 100m, Fiber ≥500m

No.	Name	Chip brand	Chip type	Wavelength	Brightness	Number
1	Red	Epistar	9mail	615-620nm	300-500mcd	1pc
2	Green	Epistar	12*13 mail	520±4nm	1100-1320mcd	1pc
3	Blue	Epistar	12*13 mail	460±3nm	260-300mcd	1pc

Shenzhen Yilong LED display Co., Ltd.Is specialized manufacturer in LED display and LED lightings, which was founded in year 2006.Yilong intergrates designing, manufacturing, sales, engineering services also after services.The quality system management ISO9001 and with many facilities as high-speed fully automated SMT machine, fully automated glue-pouring machine, reflow ovens, wave-soldering, also engineers with rich experience and skilled workers.

With an excellent quality and services, Yilong has owned rich customers'reputations both from China also from other countries in the world as Taiwan, Hong Kong, Singapore, USA, South-Africa, etc…Our main products include LED display screen single color, bi-color and full color and various modules.

Importers, buyers, distributors, wholesalers, retailers, agencies, representations, trade, suppliers, vendors are all sincerely welcomed to join Yilong will be the best partner to your further successful business.
