Product Specifications
Prod Model: |
EPS E/B/F/P grade |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Package 1: |
25kg/Paper Bag |
Package 2: |
850kg/ Bulk Bag |
CAS No.: |
3903110000 |
Mf: |
(C8h8)N |
Einecs No.: |
EPS |
Type: |
Synthetic Resin and Plastics |
Model Number: |
Normal Retardant |
Purity: |
96% |
Characteristic: |
Thermoplastic Resin |
Molecular Principal Chain: |
Carbon Chain Polymer |
Synthetic Resin: |
Polyurethane Resin |
Natural Resin: |
Copal Resin |
Color: |
White |
Product Description
1.Specifications:
Flame Retardant:C- Self Extinguishing Grade
Regular Grade:
F Fire Retardant Grade
E Standard Grade
P High Expansion Grade
B Fast Cycling Grade
2.EPS RAW MATERIAL:
E. P. S. (Expandable Poly Styrene) is a lightweight, rigid, plastic foam insulation material produced from solid particles of polystyrene.
Expansion is achieved by virtue of small amounts of pentane gas dissolved into the polystyrene base material during production. The gas expands under the action of heat, applied as steam, to form perfectly closed cells of EPS. These cells occupy approximately 40 times the volume of the original polystyrene bead.
The EPS beads are then molded into appropriate forms suited to their application. Products made from foamed polystyrene are nearly ubiquitous, for example packing materials, insulation, and foam drink cups.
EPS Fire Retardant grade is used for production EPS blocks, insulation construction material.
3.Our Producing Process
Prepoaming→Curing→Moulding→Drying→Cutting
4.Packing
25kg/paper bag, 680bags=17tons=one 20feet container
800kg/jumbo bag, 20 jumbo bags=16tons=one 20 feet container
850kg/jumbo bag, 20 jumbo bags=17tons=one 20 feet container
5.Payment and Delilvery
Trade Term: FOB,CIF
Payment Term: T/T,L/C
T/T Payment: 30% down payment in advance, balance covered before shipment.
L/C Payment: 100% irrevocable L/C at sight before shipment
Port: Shanghai
6.EPS APPLY
Roofing
Electronics
Structural Systems -- ICF
Industrial Machinery & Equipment
Foundation
Medical & Pharmaceutical
Architectural
Temperature Sensitive Packaging
Cold Storage
Geofoam
7.Our services
We highly appreciate your any enquiry by email, fax or instant message.
We will reply your email or fax within 24 hours
Please feel free to call us at any time if there is any questions.
Welcome to visit our factory, we will offer you the best price and best services
Standard Grade |
|
|
|
Code | Beads size | Foam mulfiple | Foam density(G/L) | USE |
E-301 | 1.00-1.60 | 70-85 | 12-14 | USE FOR BLOCK AND LOW DENSITY PRODUCT |
E-302 | 0.85-1.25 | 60-70 | 14-16 | USE FOR PRODUCT MORE THAN 12MM THICK |
E-303 | 0.70-0.90 | 55-65 | 15-18 | USE FOR MIDDLE DENSITY PACKING PRODUCT |
E-401 | 0.50-0.80 | 40-55 | 18-25 | USE FOR PRODUCT MORE THAN 8MM THICK |
E-501 | 0.40-0.60 | 30-40 | 25-30 | USE FOR PRODUCT MORE THAN 6MM THICK |
|
|
|
|
|
High Expansion Grade |
|
|
Code | Beads size | Foam mulfiple | Foam density(G/L) | USE |
P-301 | 1.00-1.60 | 75-90 | 11-13 | USE FOR ELECTRIC PACKING BLOCK |
P-302 | 0.85-1.25 | 65-75 | 13-15 | CRAFTWORK, BOX ETC,ESPECIALLY USE FOR |
P-303 | 0.70-0.90 | 55-70 | 14-18 | LOW DENSITY BLOCK |
P-401 | 0.50-0.80 | 45-55 | 18-20 |
|
P-501 | 0.40-0.60 | 40-50 | 20-25 |
|
|
|
|
|
|
Fire Retardant Grade |
|
|
Code | Beads size | Foam mulfiple | Foam density(G/L) | USE |
F-301 | 1.00-1.60 | 70-85 | 12-14 | USE FOR BLOCK |
F-302 | 0.85-1.25 | 60-70 | 14-16 | USE FOR BLOCK AND BIG PACKING PRODUCT |
F-303 | 0.70-0.90 | 50-65 | 15-18 | USE FOR BLOCK AND BIG PACKING PRODUCT |
F-401 | 0.50-0.80 | 40-50 | 18-25 | USE FOR BLOCK AND MIDDLE DENDITY PACKING PRODUCT |
F-501 | 0.40-0.60 | 30-45 | 25-30 | USE FOR HIGH DENSITY BLOCK AND SPECIAL USE PRODUCT |
|
|
|
|
|
Fast Cycling Grade |
|
|
Code | Beads size | Foam mulfiple | Foam density(G/L) | USE |
B-301 | 1.00-1.60 | 55-70 | 14-18 | USE FOR ELECTRIC PACKING, BLOCK AND CHINA PACKING AND HIGH DENSITY PROUDUCT |
B-302 | 0.85-1.25 | 50-60 | 16-20 |
B-303 | 0.70-0.90 | 40-55 | 18-25 |
B-401 | 0.50-0.80 | 35-45 | 22-30 |
B-501 | 0.40-0.60 | 30-40 | 25-35 |
Specification | E301 | E302 | E303 | E401 | E501 |
Beads Size mm | 1.00-1.60 | 0.85-1.25 | 0.70-0.90 | 0.50-0.80 | 0.40-0.60 |
Vol.Cont % | 6.80 | 6.77 | 6.59 | 6.32 | 6.10 |
H2O % | 0.39 | 0.43 | 0.40 | 0.45 | 0.40 |
F.M % | ≤0.30 | ≤0.30 | ≤0.30 | ≤0.30 | ≤0.30 |
Avg.size mm | 1.35 | 1.02 | 0.81 | 0.63 | 0.50 |
PRE-EXPENSION DENSITY | 12.0-14.0 | 14.0-16.0 | 15.0-18.0 | 18.0-25.0 | 25.0-30.0 |
Sieving ≥ 95% | 95.00 | 95.00 | 95.00 | 95.00 | 95.00 |
Result(g/l) | 12.50 | 14.50 | 17.38 | 20.67 | 26.18 |
| Max(I) | 12.11 | 14.76 | 15.53 | 18.29 | 25.38 |
DENSITY | (g/l) |
RANGE | Mix(I) | 14.00 | 15.38 | 17.67 | 24.18 | 29.12 |
| (g/l) |
Remark | ALL THE DATA IS BASED ON LAB TEST FOR FIRST TIME EXPANSION IN CONTINOUS EXPANDER |
|
Specification | F301 | F302 | F303 | F401 |
|
Beads Size mm | 1.00-1.60 | 0.85-1.25 | 0.70-0.90 | 0.50-0.80 |
|
Vol.Cont % | 6.85 | 6.8 | 6.66 | 6.27 |
|
H2O % | 0.95 | 1.12 | 1.25 | 1.26 |
|
F.M % | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.10 |
|
Avg.size mm | 1.32 | 1.01 | 0.8 | 0.63 |
|
PRE-EXPENSION DENSITY | 12.0-14.0 | 14.0-16.0 | 15.0-18.0 | 18.0-25.0 |
|
Sieving ≥ 95% | 95.0 | 95.0 | 95.0 | 95.0 |
|
Result(g/l) | 13.67 | 15.18 | 17 | 23.22 |
|
| Max(I) | 12.58 | 14.58 | 16.67 | 19.00 |
|
DENSITY | (g/l) |
|
RANGE | Mix(I) | 14.00 | 16.00 | 18.00 | 24.33 |
|
| (g/l) |
|
Oxygen Index | ≥30 | ≥30 | ≥30 | ≥30 |
|
Remark | ALL THE DATA IS BASED ON LAB TEST FOR FIRST TIME EXPANSION IN CONTINOUS EXPANDER |
|
|
|
|
|
|
|
|
|
Specification | P301 | P302 | P303 | P401 | P501 |
Beads Size mm | 1.00-1.60 | 0.85-1.25 | 0.70-0.90 | 0.50-0.80 | 0.40-0.60 |
Vol.Cont % | 7.81 | 7.66 | 7.39 | 7.09 | 6.82 |
H2O % | 0.45 | 0.57 | 0.38 | 0.51 | 0.37 |
Avg.size mm | 1.25 | 1.01 | 0.81 | 0.63 | 0.53 |
Sieving ≥ 95% | 98.00 | 100.00 | 100.00 | 100.00 | 99.80 |
Result(g/l) | 12.50 | 13.50 | 14.33 | 18.67 | 20.20 |
| Max(I) | 11.00 | 13.11 | 14.50 | 18.67 | 20.20 |
DENSITY | (g/l) |
RANGE | Mix(I) | 12.50 | 14.28 | 17.67 | 20.00 | 25.00 |
| (g/l) |
Remark | ALL THE DATA IS BASED ON LAB TEST FOR FIRST TIME EXPANSION IN CONTINOUS EXPANDER |
|
Since 1999 we entered into EPS business line, we have involved in this industry for more than 12 years. Our company mainly focus on EPS scientific research and development, technical support, and EPS consult information.
In China, we are familiar with domestic developing trends of EPS industry. Here we emphasize on the promotion of EPS raw materials and advanced equipments from abroad, and we help our customers to solve some technical problems during processing, even produce some colored materials for them according to their clients' Demands. We are concerned about EPS raw material prices trends at any time, thus we help our customers save raw material purchasing costs and procurement costs. With many years' Cooperation experience with major shipping companies like MAESK, MSC, COSCO, etc., we ensure our cargoes booking and sailing timely. Through all these efforts so that we can enhance our customers' Competitiveness.
Abroad, we are committed to the promotion of the EPS block machine, packaging machine and automatic cutting line origin from China with Chinese characteristics, high quality & reasonable price. We have erected a bridge for worldwide EPS users engaged in EPS industry to communicate better with each other. Therefore, our customers save a lot of travel costs and time, especially reduce a large number of losses due to quality claims in the disputes with our familiar Chinese laws. We' Re not proud of selling cheap products to our customers, but proud of helping our customers solve purchasing problems.
We also devoted a lot in recycling EPS waste. We gather waste EPS in China, and promise to our customers to recycle waste EPS around the world. We processed these waste EPS into a variety of beautiful and useful products. In this point, we pride for reducing the white pollution, and saving energy for the community.
In China, only a company like us, can engage in areas range from raw materials, equipments and recycling granulations with technical supports, and play endless important role in the whole industrial chain.
Concentrate, so we are professional. You are always our concern centre.
