Expanded Mesh Safety Grating

Name: Expanded Mesh Safety Grating
Brand: china-manufacturer-directory.com
SKU: 687721842
Availability: InStock
Rating: 5 (119 reviews)

Price:	US $ 30/Square Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	50/Square Meter
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Expanded Mesh Safety Grating

Expanded metal grating is produced from carbon steel, aluminum, or stainless steel plate. Contains no joints or welds, each sheet is a single piece of sturdy steel.

Applications:
Mezzanines
Maintenance platforms
Elevated walkways
Ramps
Security platforms
Transport protection
Industrial stairs
Doors
Window protection
Cold storage
Vehicle flooring

Advantages:
Anti-slipping surface offers great walking safety.
Open surface avoids dirt and grease accumulation.
Minimum fire prevention cost.
Low maintenance cost.
Facilitates handling & installation.
Lower cost compared to traditional bar gratings

Carbon Steel Standard Grating
Style	Lbs. Per 100 sq. ft	Design Sizes (Inches)		Opening Size (Inches)		Approx. Strand Size (Inches)		Overall Thickness (Inches)	Approx. No. Diamonds Per Ft.		Open Area %
		SWD	LWD	SWO	LWO	Thickness	Width		SWD	LWD
3.00	300	1.33	5.33	0.940	3.44	.183	.261	.540	9	2.25	73
3.14	314	2.00	6.00	1.625	4.88	.250	.308	.656	6	2	74
4.00	400	1.33	5.33	0.940	3.44	.215	.297	.618	9	2.25	65
4.27	427	1.41	4.00	1.000	2.88	.250	.297	.625	8.5	3	58
5.00	500	1.33	5.33	0.813	3.38	.250	.327	.655	9	2.25	52
6.25	625	1.41	5.33	0.813	3.38	.312	.347	.715	8.5	2.25	55
7.00	700	1.41	5.33	0.813	3.38	.312	.388	.740	8.5	2.25	60

Aluminum Grating
Style	Lbs. Per 100 sq. ft	Design Sizes (Inches)		Opening Size (Inches)		Approx. Strand Size (Inches)		Overall Thickness (Inches)	Approx. No. Diamonds Per Ft.		Open Area %
		SWD	LWD	SWO	LWO	Thickness	Width		SWD	LWD
2.00	200	1.33	5.33	.940	3.44	.250	.371	.730	9	2.25	48

Stainless Steel Grating
Style	Lbs. Per 100 sq. ft	Design Sizes (Inches)		Opening Size (Inches)		Approx. Strand Size (Inches)		Overall Thickness (Inches)	Approx. No. Diamonds Per Ft.		Open Area %
		SWD	LWD	SWO	LWO	Thickness	Width		SWD	LWD
3.30	330	2.00	6.00	1.625	4.88	.250	.312	.656	6	2	69
4.50	450	1.41	4.00	1.508	2.88	.250	.300	.625	8.3	3	58

Prod Model:	expanded Mesh Safety Grating
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Expanded Grating:	Expanded Metal Grating
Other Material:	Carbon Steel, Aluminum, Stainless Steel
Material:	Galvanized Sheet Plate
Application:	Protecting Mesh
Hole Shape:	Diamond
Weave Characteristic:	Tensile
Surface Treatment:	Galvanized

Anping Yunde Metal Co., Ltd is located at the metal wire mesh production base in Anping County name as China Wire and wire mesh Town. Our main products are Expanded Metal, Perforated Metal, Bar grating Welded Wire Mesh, Crimped Wire Mesh, Stainless Steel Wire mesh, Chain Link Fence.
