Hangzhou Titanmac Construction Machinery Co., Ltd. >> External Vibrator Motor (05 Size,Cast Iron,Adjustable Centrifugal Force,CE by TUV)

External Vibrator Motor (05 Size,Cast Iron,Adjustable Centrifugal Force,CE by TUV)

Name: External Vibrator Motor (05 Size,Cast Iron,Adjustable Centrifugal Force,CE by TUV)
Brand: china-manufacturer-directory.com
SKU: 678333592
Availability: InStock
Rating: 4.3 (130 reviews)

Supplier:	Hangzhou Titanmac Construction Machinery Co., Ltd.
Price:	US $ 350-400/Piece
Min Order:	1/Piece
Quantity::
Trade Terms:	FOB,CFR,EXW

Product Specifications

Prod Model:	ZF-T4/300
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Certificate:	CE certificate by TUV
High Quality Bearings:	NSK bearings/SKF bearings
Smooth Surface:	Cast iron housing
Easy To Change The Force:	Adjustable Centrifugal force
Type:	Similar with OLI motor
Class:	IP65, F insulation class

Product Description

High quality External Vibration Motors ZF-T series:
Advantages:
1. Centrifugal force: Adjustable
2. Protection class: F, Insulation class: IP65
3. NSK import bearings
4. Italian design, beautiful appearance
5. Cast-iron or aluminum frame can be choosen
6. 220V/380V, 230V/400V and other voltages according to customers' requirements, 50Hz/60Hz
7. High quality packing carton and standard instruction.
ZF-T series vibrator motor, as the general vibrating source, its characteric is light weight, small volume, easy adjustment of vibrating force. They can be vibrating source for vibrating onveyor, vibrating feeder, vibrating screens, filter, concrete forms, vibrating polisher, vibrating drier and close-proof device for block during vibrating ect., widely used in mining, metallurgy, coalindustry, electric power, construction, chemical industry, casting, food and light industry etc. Aluminium is used for the housings of low power units, nodular cast iron used for the housings of high power units, which can greatly reduce the weight of integral equipment, increase the capacity of the integral equipment to handle the material. The vibrating force can be easily changed within the certain scope to satisfy various requirements.

ITEM NO.	VIBRATION FORCE		MAX. INPUT POWER(W)	MAX. CURRENT (A)	PHASE	POLE	WEIGHT (KGS)	MOTOR SIZE	MATERIAL OF MOTOR
ITEM NO.	KN	KG· f	MAX. INPUT POWER(W)	MAX. CURRENT (A)	PHASE	POLE	WEIGHT (KGS)	MOTOR SIZE	MATERIAL OF MOTOR
ZF-T2/20	0.2	20	20	0.1	3-PHASE	2	1.3	00AL	ALUMINUM
ZF-T2/60	0.7	71	130	0.24	3-PHASE	2	5.8	01AL	ALUMINUM
ZF-T2/100	1.0	102	160	0.3	3-PHASE	2	6.0	01AL	ALUMINUM
ZF-T2/200	1.9	200	170	0.32	3-PHASE	2	7.0	01AL	ALUMINUM
ZF-T2/300	2.9	300	320	0.58	3-PHASE	2	16.5	02	CAST-IRON
ZF-T2/300	2.9	300	320	0.58	3-PHASE	2	11.0	02AL	ALUMINUM
ZF-T2/500	4.9	505	440	0.8	3-PHASE	2	20.0	03	CAST-IRON
ZF-T2/800	7.9	810	550	1	3-PHASE	2	25.2	03	CAST-IRON
ZF-T2/1300	12.8	1306	1100	2	3-PHASE	2	39.0	04	CAST-IRON
ZF-T2/1500	14.9	1520	1200	2.15	3-PHASE	2	40.0	04	CAST-IRON
ZF-T2/1800	18	1837	1450	3.2	3-PHASE	2	45.0	04	CAST-IRON
ZF-T2/2300	22.6	2310	1800	4	3-PHASE	2	48.5	04	CAST-IRON
ZF-T2/3200	32	3250	2300	6.5	3-PHASE	2	100.0	05	CAST-IRON
ZF-T2/4000	40	4030	3200	7	3-PHASE	2	105.0	05	CAST-IRON
ZF-T2/5000	50	5070	4150	7.8	3-PHASE	2	115.0	05	CAST-IRON
ZF-T4/40	0.4	45	40	0.1	3-PHASE	4	6.8	01AL	ALUMINUM
ZF-T4/80	0.8	80	94	0.24	3-PHASE	4	7.1	01AL	ALUMINUM
ZF-T4/200	2	210	200	0.4	3-PHASE	4	16.8	02	CAST-IRON
ZF-T4/400	4.0	410	360	0.65	3-PHASE	4	22.0	03	CAST-IRON
ZF-T4/500	5.0	510	390	0.7	3-PHASE	4	26.0	03	CAST-IRON
ZF-T4/700	6.9	700	550	0.98	3-PHASE	4	28.0	03	CAST-IRON
ZF-T4/1400	13.8	1410	850	1.5	3-PHASE	4	42.0	04	CAST-IRON
ZF-T4/1700	16.8	1720	1100	2	3-PHASE	4	46.0	04	CAST-IRON
ZF-T4/2400	23.6	2410	1500	3	3-PHASE	4	50.0	04	CAST-IRON
ZF-T4/3000	30	3060	1700	4	3-PHASE	4	102.0	05	CAST-IRON
ZF-T4/3800	38	3830	2200	5	3-PHASE	4	118.0	05	CAST-IRON
ZF-T4/5000	50	5010	3500	5.3	3-PHASE	4	180.0	06	CAST-IRON
ZF-T4/7500	75	7560	4500	6.8	3-PHASE	4	350.0	07	CAST-IRON
ZF-T4/10000	100	10110	5500	7.5	3-PHASE	4	430.0	07	CAST-IRON
ZF-T6/1000	10	1000	750	1.2	3-PHASE	6	55.0	04	CAST-IRON
ZF-T6/1500	15	1510	1000	1.7	3-PHASE	6	80.0	04	CAST-IRON
ZF-T6/2000	20	2030	2200	3.1	3-PHASE	6	138.0	05	CAST-IRON
ZF-T6/3000	30	3060	2600	4	3-PHASE	6	179.0	06	CAST-IRON
ZF-T6/5000	50	5060	4100	6.2	3-PHASE	6	195.0	06	CAST-IRON
ZF-T6/7500	75	7570	5500	8.1	3-PHASE	6	370.0	07	CAST-IRON
ZF-T6/10000	100	10100	7500	11	3-PHASE	6	460.0	07	CAST-IRON
ZF-T2/20D	0.2	20	20	0.1	1-PHASE	2	1.3	00AL	ALUMINUM
ZF-T2/60D	0.6	62	86	0.43	1-PHASE	2	6.0	01AL	ALUMINUM
ZF-T2/100D	1	110	120	0.58	1-PHASE	2	6.4	01AL	ALUMINUM
ZF-T2/200D	2	210	150	0.71	1-PHASE	2	8.5	01AL	ALUMINUM
ZF-T2/300D	3	311	253	1.2	1-PHASE	2	17.2	02	CAST-IRON
ZF-T2/300D	3	311	253	1.2	1-PHASE	2	11.5	02AL	ALUMINUM
ZF-T2/500D	4.9	500	475	2.25	1-PHASE	2	21.0	03	CAST-IRON
ZF-T2/800D	7.8	800	686	3.25	1-PHASE	2	26.0	03	CAST-IRON

Hangzhou TitanMac Construction Machinery Co., Ltd, as sister company of Focatt Construction Machinery Co., Ltd. Dedicate to manufacture excellent and innovative construction machinery and is one of the professional export base for construction powered equipment in China.

Currently our product range covers plate compactors, power trowels, concrete vibrators and other concrete products. It continuously diversifies its products range according to customer needs.

Our products have CE approvals and some meet the requirements of the UL, GS Directives. We are professional and sincere, with ceaseless innovation and effort, we aspire to not only meet but also exceed our client's requirements. It provides long-term opprtunities for Focatt to continue Grow.

TITANMAC holds some advanced processing equipments. Advanced technology and technoligical process, constant innovation of product and advanced equipment lead to both increasingly expanded production capacity and steadily improved quality.

Spirit: Service, Quality, Sincerity.

Service: TITANMAC believes that Good service is more important than profit, we hope to keep long-term business relationship instead of one-time order. We accept sample order for clients to test quality and we are confident of this.

Quality: It is not only the most important point for our customers, but also for us. Cheap price receive order but once, good quality is the base of long-term business. We believe that Better Machinery, Better Results.

Sincerity: Sincerity is our foundation of cooperation with our clients, we seek to maximize value for our clients and be the most valuable partner. Above all, we find joy in our work, and in serving the company and our customers.

TITANMAC are dedicated to providing the highest quality tools at the most competitive prices in the market place, passing on the savings made by running an efficient and effective operation, so you get the right tool at the right price. That's why Focatt are the number one choice for thousands of merchants, retailers and tool users in Europe and the world.
