Product Specifications
| Prod Model: |
SSDJ-2045 |
| Type: |
Insulating Glass Production Line |
Product Description
1)Main technical parameter:
Full pneumatic type
Input Air pressure 0.4-0.6MPa
Air consumption 800L/min
Air motor's pressure 12-28MPa
Max Extruding output 60kg/h
A and B sealant's Mixture ratio 8: 1~13: 1
Pump A platen diameter ø 565mm
Pump B platen diameter ø 285mm
Dimension 1100mm*770mm*1700mm
Weight 350 kg
2)Structure Feature:
This extruder is the full pneumatic type extruder. It is made up of air motor A, air motor B, lift & down structure A, lift & down structure B, machine framework, pneumatic system. Adopted the newest technology and design, the whole machine's installation and maintenance are very convenient and economic.
3)Function Explanation:
This extruder is the special machine for spreading dual-component sealant. It is full pneumatic type and do not need electric supply, can be easy to move and operation in the building site. Easy operation, easy maintenance, stable working, high efficiency, It can suit the request of insulating glass & glass curtain wall batch production.
Jinan Oberon Technical Co., Ltd. is the professional manufacturer & exporter for PVC window and door processing machinery, aluminium window and door processing machinery, double sealed insulating glass machinery under the brand "CBM". All CBM machinery have been exported more than 12 years. We also offer maintenance service, window tools, spare parts, hardwares according to customers' Requestion.
High quality and perfect service are our base.
We would like to develop our sincere cooperation with you for better future.
