Product Specifications
| Prod Model: |
IN-I5S |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Core Code: |
Haswell |
| Size: |
197*197*29mm |
| Weight: |
2.5kgs |
| CPU: |
Intel |
| GPU: |
Intel |
| Memory Type: |
DDR3 |
| Use: |
Commercial |
| CPU Frequency: |
1.5-2.0GHz |
| Memory Capacity: |
2g/4G/8g/16g |
| HDD Capacity: |
80g/160g/250g/320g/500g/1tb |
Product Description
| Model | IN-I5S i5 4200U |
| General |
| CPU | Onboard Intel Core i5 4200U 1.6GHz Max 2.6GHz(Turbo boost Technology)Dual Core 4 thread |
| Clock Speed | 1.6GHz(100MHz x 16.0) |
| Turbo clock Speed | 2.6GHz |
| Processor Number | 2 core/ 4 threads |
| Core code | Haswell |
| Technique | 22nm |
| L1 data cache | 2 * 32 KB, 8-Way, 64 byte lines |
| L2 code cache | 2 * 32 KB, 8-Way, 64 byte lines |
| L3 cache | 3 MB, 12-Way, 64 byte lines |
| Characteristic | MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4, AVX2.0, SSE4.2, HTT |
| BIOS | AMI BIOS, ACPI supported,
Support call on function automatically,
Wake-On-LAN |
| Motherboard | Intel SHARKBAY(Intel Haswell-ULT) |
Memory
Memory Type | 2GB/4GB/8GB/16GB DDR3L 1.35V Voltage
DDR3L-1600, DD3L-1333, LPDDR3-1600, LPDDR3-1333 |
| Storage | SSD: 8GB/16GB/32GB/64GB/128GB/256GB
HDD: 80GB/160GB/320GB/500GB/750GB/1TB |
| Operating System | Windows (OEM) or Linux |
| Graphic Cards | Intel Haswell- ULT Integrated Graphics Controller
Intel HD Graphics 4400(200~1000MHz) |
| Audio Cards | ALC662 sound chip, 6-channel
Intel Panther Point HDA |
| Network card | RTL8168E PCI-E Gigabit Ethernet NIC |
| Ethernet | 10/100/1000 BaseT LAN |
| WIFI | With dual antenna, 802.11.b/g/n(150M or optional 300M) |
| I/O Ports |
| Display port | 1* VGA + 1 * HDMI |
| USB port | 4* USB 3.0, 2 * USB2.0 |
| SATA port | 1 * MSATA3.0, 6Gb/s; 1 * SATA3.0 , 6Gb/s |
| MINI PCIE | 1 * MSATA SSD, 1 * WiFi module |
| Ethernet port | RJ45 10/100/1000 Mbps Adaptive |
| Power input port | 1 inner diameter 2.5mm,external diameter 5.5mm |
| Audio port | Standard 3.5 Audio input and output |
| Power and Working Environment |
| Input | DC100-240V AC/50-60Hz |
| Output | DC 12V/3A |
| Consumption | 15W |
| Noise | Fanless System |
| Temperature | 0-70 Centigrade |
| Relative Humidity | 10%~90%(non-condensing) |
| Function | Hyper-Threading, Virtualization technology, 64 bit computing |
| Product Dimension&Details |
| Size | 197*197*29MM |
| Weight | 2.5KG |
| Case Thickness | 2.9MM |
| Shell | Silver |
| Package Box | Neutral Color Box or INCTEL Color Box |
| Content | Mini PC device, Power Adapter, Desk base, Antennas (For Optional) |
Features and Advantages:
- Beautiful: Industrial aesthetic design and Reasonable interface layout
- Noiseless: Fanless system, low consumption, 0.00dB noise
- Special: Support 64 bits computing Turbo boost Hyper-Threading Virtualization technology etc, Can install 1pc 2.5'' HDD and 1pc MSSD(5CMx3CM) together(welcome to contact our Pre-Sales if you need it) up to 512GB SSD or 1TB Hardisk large volume;
-Stable: Intel Core i5+Haswell structure+ Intel HD4400 Graphics+Fanless, be able to work 24hours per day
- Slim: Only 29mm body thickness, can stand on desk by free bracket we supply
- Smooth: Support XBMC, 3D games, blue-ray and 4K Ultra HD streams, full 1920*1080 HD resolution
- Strong: Work with any brand monitors; Suit for multiple application for example integrate with touch devices, industries, car repair shops, security, education, home as HTPC, business, fanancial and projects
-Low-carbon green: TDP only 15W, very economical, saving a lot energy every year, low consumption but with a very amazing performance
Main Application Field:
- Living Room as Home Theater Personal Computer(HTPC). Connect your TV with the HDMI cable, you can enjoy education online and play internet movies or games.
- Internet Bar. High speed Gigabit Ethernet and diskless certificate, support 3D games.
- Office. High performance, tiny size, smart design, support Windows XP/7/ Linux system, multi USB ports for data transfer, long time working.
- Hotel Rooms. Diskless, locally run, smart design, upgrading hotel service
- As Mini Cloud Terminal Server, Dual Ram slots, Max 16GB DDR3 and 1TB HDD
