| Price: | US $ 46500-56500SET |
|---|---|
| Trade Terms: | FOB,CFR,EXW |
| Min Order: | 1SET |
| Pay Type: | L/C,T/T |
| Prod Model: | CA3310 |
|---|---|
| Markets: | South America,Southeast Asia,Africa,Mid East,Eastern Asia |
| Truck Type: | Dump Truck |
| Dumping Type: | Front Lifting Style |
| Engine Capacity: | ＞8L |
| Horsepower: | 351-450hp |
| Condition: | New |
| Drive Wheel: | 8?á4 |
| Emission Standard: | Euro 2 |
| Tire Design: | Radial |
| Tire Certification: | ISO |
| Tire Type: | Inner Tube |
| Load Capacity: | 41-50t |
| Power: | Diesel |
| Transmission Type: | Manual |
| Seats: | 3 |
FAW 50 Tons Dumper Trucks
FAW 40-50 tons dump trucks
1.WEICHAI 340,380HP
2.EATON clutch
3.America parts
4.EATON/ FULLER gearbox
5.Front lift or middle lift
6.Steel Cabin for comfortable drive
7.WABCO valve
8.USA TRW steering
9. NORGREN solenoid valves
10.KOREAN GLOBAL free-maintenance battery
11.American TFLOCK self-locking nuts
12.American WOODWARD speed governor
13.GEMAN VOITH retarder
14.American TUTHILL cable
15.CVG American driver seat
16.American TENNECO shocker
17.AMP plug connector
Q: What's the brand of your truck?
A: Our brand is FAW, First Automobile Works is the biggest truck manufacture in China, our products cover all series such as tractor truck, tipper truck, cargo truck, and other special trucks.
Q: How can we trust your company?
A: We are the official authority company by FAW Qingdao Automobile Company. And we are registered in the Commercial Department of China, with the whole qualification for exporting, you would feel relax and safe to do business with us. We are your reliable partner.
Q: Can u provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed.
Q: How about warranty item?
A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.
FAW 380HP,340HP, 40-50T, Dump truck, tipper truck
packing usually in nude,shipping by RORO or bulk carrier ship, also we can do CKD or SKD
Warranty, technical training, spare parts surpplying ,Phone or mail support
The first automobile anufacturer,has a history more than 45years, business expanded to asia,africa,south america and all over the world,More than 10000 units producing capacity, ISO 9001,TS16949,ISO14001,OHSMS18001 certificate
FOB or CIF terms, T/T or L/C, small order is accepted
Optional:silicon oil fan, driving recorder, right hand driving,
Pto is included in tipper chassis.
Cargo body:
Volume range: 25-35m3
Thickness bottom 10 mm, side 6 mm(can be increased)
Hydraulic lifting system with f type, t type and front lift type(hiva brand is optional).
| Dimension(L×W×H)mm | 10345×2496×3470 | |
| Cargo body size (L×W×H) (mm) | 7400/7600x2300x1500 Sand body, side 6mm bottom 8mm,Middle lifting system | |
| Approaching angle/Departure angle(° | 19/21 | |
| Overhang(front/rear) (mm) | 1500/2070 | |
| Wheel base (mm) | 1860+3625+1350 | |
| Max speed(km/h) | 75 | |
| Curb weight(kg) | 12460 | |
| Loading Weight(kg) | 12410 | |
| Actual loading Weight(Kg) | 40000-50000kg | |
|
Engine Steyr technology, made in China |
Model | WP10.380,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection |
| Fuel type | Diesel | |
| Power, | 213/2200 | |
| Emission | EURO 2 | |
| Fuel tanker capacity (L) | 300 | |
| Transmission | Model | FAST 12JS160T,12 forward&2 reverse |
|
Brake system |
Service brake | Dual circuit compressed air brake |
| Parking brake |
spring energy, compressed air operating on rear wheels |
|
|
Steering system |
Model | TRW |
| Front axle | Steering with double T-cross section beam T | |
| Rear axle | Pressed axle housing, central double reduction with differential locks between axles and wheels | |
| Tyre | 12.00R20 STEEL RADIAL TIRE | |
|
Electrical system |
Battery | 2X12V/180Ah |
| Alternator | 28V-1500kw | |
| Starter | 7.5Kw/24V | |
| Cab |
HOWO76 Standard cab, all-steel forward control,55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers |
|
