Fiber Optic FTTX 1X8 Cassette Type PLC Splitter
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,EXW |
| Min Order: |
6/Piece |
| Pay Type: |
L/C,T/T,Western Union |
Product Specifications
| Markets: |
North America,Africa,Western Europe |
| Model No: |
1*N |
| Name: |
PLC Splitter |
| Application: |
Communication, CATV, Epon |
| Fiber Type: |
9/125 SMF-28e |
| Price: |
Competitive |
| Connector: |
FC, Sc, St, LC, Mu, MTRJ, DIN, MPO |
| Feature: |
High Quality |
| Package: |
Carton |
| Size: |
Can Be Custimized |
| Box: |
ABS or Lgx |
| Certification: |
RoHS |
| Condition: |
New |
Product Description
Fiber optic FTTX 1X8 Cassette type PLC Splitter
l Low Insertion loss
l Low PDL
l Compact Design
l Good channel-to-channel uniformity
l Wide Operating Wavelength: From 1260nm to 1650nm
l Wide Operating Temperature: From -40ºC to 85ºC
l High Reliability and Stability
Applications
l FTTX Systems
l PON Networks
l CATV Links
l Optical Signal Distribution
Compliance
l Telcordia GR-1209-CORE
l Telcordia GR-1221-CORE
l RoHS
About us:
1×N PLC Splitter
| Parameters | 1×2 | 1×4 | 1×8 | 1×16 | 1×32 | 1×64 | 1×128 |
| Operating Wavelength (nm) | 1260~1650 |
| Fiber Type | G657A1 or customer specified |
| Insertion Loss (dB)(P/S Grade) | 3.8/4.0 | 7.1/7.3 | 10.2/10.5 | 13.5/13.7 | 16.5/16.9 | 20.5/21.0 | 23.8/24.2 |
| Loss Uniformity (dB) | 0.4 | 0.6 | 0.8 | 1.2 | 1.5 | 2.0 | 2.5 |
| Polarization Dependent Loss(dB) | 0.2 | 0.2 | 0.2 | 0.25 | 0.3 | 0.35 | 0.4 |
| Return Loss (dB)(P/S Grade) | 55/50 | 55/50 | 55/50 | 55/50 | 55/50 | 55/50 | 55/50 |
| Directivity (dB) | 55 | 55 | 55 | 55 | 55 | 55 | 55 |
| Wavelength Dependent Loss (dB) | 0.3 | 0.3 | 0.3 | 0.5 | 0.5 | 0.5 | 0.5 |
Temperature Stability
(-40~85 ºC)(dB) | 0.4 | 0.4 | 0.4 | 0.5 | 0.5 | 0.5 | 0.5 |
| Operating Temperature (ºC) | -40~85 |
| Storage Temperature (ºC) | -40~85 |
| Device Dimension (mm) | 40×4×4 | 40×4×4 | 40×4×4 | 50×4×4 | 50×7×4 | 60×12×4 | N/A |
| Module Dimension (mm) | 100×80×10 | 100×80×10 | 100×80×10 | 120×80×18 | 140×115×18 | 140×115×18 | 140×115×18 |
| Mini-Module Dimension (mm) | 50×7×4 | 50×7×4 | 50×7×4 | 60×12×4 | 80×20×6 | 100×40×6 | N/A
|
Notes:
1. Specified without connectors.
2. IL will be 0.15dB higher with connectors.
3. For more information about 2xN PLC splitter, please refer to our PDF datasheet.
