Product Specifications
| Prod Model: |
SR1828; SR1829 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
SR1828 Field Intensity Meter
The meter can inspect particular objects or devices radiate low frequency electromagnetic waves. It can use for power wire, computer monitor, TV, audio and visual, electromagnetic oven oven or analogous electrical installation.
Measuring range:
0.1-400mG, 1-4000mG
0.01-40uT, 0.1-400uT
Accuracy: ±(3%rdg+3digits) 50Hz/60Hz
Proper frequency: 30Hz-400Hz
Exceed measuring range: LCD will display "OL"
Sampling time: 0.5 second
Power: one 9V battery (model 6F22)
Operating environment:
Temperature: 0-50 degree Celsius (32-122 Fahrenheit degree)
Relative humidity: ≤80%RH
Dimensions: 138L*71W*35H(mm)
SR1829 Field Intensity Meter
1.Metrical ways:digit display,measuring with three axes
2.Characteristic of directivity:all-aspect,three axes
3.Resolutin displayed:0.1mV/m,0.1uA/m,0.1uW/M2
4.Reaction time: about 1 second(the measurement value is from 0 to 90%)
5.Refresh rate displayed:about 0.5 second
6.Display format:LCD,4 digits
7.Alarm:buzzer
8.Units:mV/m,V/m,uA/m,mA/m,uW/m2,mW/m2,uW/cm2
9.Displayed value:the instantaneous measurement value,the MAX measurement value,average measurement value and the maximum averaging value Warning function:you can adjust the setting value and you also can open the function or close it.
10.Manual memory and reading data content:99 groups
11.Power:4×1.5V AA battery
12.Operating environment: (Temperature: 0-50 degree Celsius(32-122 Fahrenheit degree)
13.Relative humidity: ≤80%RH
14.Dimensions and weight: 261L×73W×38H(mm)
