Fireproof Aluminum Plastic Composite Panel
| Price: |
Negotiable |
| Trade Terms: |
by Sea or by Air |
| Min Order: |
500/Square Meter |
| Pay Type: |
L/C,Western Union |
Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Surface Finishing: |
Color Printing |
| Function: |
Fireproofing |
| Usage: |
Curtain Wall |
Product Description
Product Description
Aluminum Composite Panel (Aluminum Plastic Composite Material) consists of two sheets of smooth 0.5mm aluminum thermobonded to a polyethylene core in a continuous process.
Aluwell ACP is pre-finished with a premium Kynar 500 PVDF resin-based coil coating that is available in a spectrum of attractive standard colors along with any custom color you desire. To allow for imaginative design and creativity Aluwell ACP comes in a variety of lengths and widths.
Aluwell ACP is used as cladding for many diverse applications such as office buildings, hospitals, convention centers, airports, hotels and for critical design elements such as entrances, canopies, column covers and interiors. With Aluwell ACP you add a crisp clean metal look that will add an image premium to any application.
|
Commodity: |
Aluminum Composite Panel / Material |
|
Brand Name: |
ALUWELL & OEM available |
|
Fire-rating: |
Grade A & B1 & B2 |
|
Surface Finish: |
PVDF & FEVE & Polyester & PET Film & Wooden Finish & Stone Finish & Brush Finish & Mirror Finish |
|
Certificates and Test Reports |
ISO 9001:2000, ISO14001, ROHS, OHSMS, ASTM E-84, DIN, SGS Test Report according to ASTM |
|
Samples: |
Free charge of samples and catalogue, but courier charges collect. |
|
Panel Dimensions: |
Thickness (mm) |
2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm |
|
Skin Thickness (mm) |
0.12mm, 0.20mm, 0.30mm, 0.40mm, 0.45mm, 0.50mm |
|
Width (mm) |
1000mm, 1220mm, 1250mm, 1500mm, 1570mm, 2000mm |
|
Length (mm) |
2050mm, 2440mm, 3050mm, 4050mm, 5200mm, 5800mm, 6000mm |
|
Color: |
More than 30 kinds standard color and RAL color available |
|
Application: |
Interior Decoration, Exterior Wall Cladding and Sign |
|
Dimensional Tolerances |
Thickness(mm) |
±0.2 |
|
Width(mm) |
±2 |
|
Length(mm) |
±3 |
|
Diagonal(mm) |
±5 |
|
Themal Expansion |
2.4mm/m @100 oC Temp Difference |
|
Aluminium Thickness(mm) |
±0.02 |
|
Surface Properties |
Pencil Hardness |
>HB/>2H |
|
Temperature Resistance |
-50 oC to +80 oC |
|
Impact strength(kg.cm) |
50 |
|
Bolling Resistance |
Boiling for 2 hours without change |
|
Acid Resistance |
Immerse Surface in 2% HC1 for 48 hours without change |
|
Alkaili Resistance |
Immerse Surface in 2% NaOH for 48 hours without change |
|
Oil Resistance |
Immerse Surface in 20# engine oil for 48 hours without change |
|
Solvent Resistance |
Cleaned 100 times with Dimethylbezene without change |
|
Cleaning Resistance |
Over 1000 times without change |
|
Peel Strenght 180 oC |
180oC>5 Newton/mm |
|
Product Properties |
Sound Absorbtion NRC |
0.05 |
|
Sound Attenuation Rw db |
23/24/25 |
|
Water Absorbtion % by volume |
0.0047/0.0057/0.0012 |
|
Core Composition |
LDPE Polyethylene, Non- Combustible Material |
Guangzhou Aloya Renoxbell Aluminum Co., Ltd, located in Panyu district of Guangzhou, is a professional and experienced manufacturer of high-tech titanium-zinc composite panel, titanium composite panel, stainless steel composite panel, copper composite panel, fireproof composite panel, aluminum composite panels, stone honeycomb panel, aluminum honeycomb panels, heat preservation panel, and other curtain wall building and decoration materials. Based on 10 years experience in this industry, RENOXBELL has an annual production capacity of 1 million square meters of aluminum composite panel, and 0.8 million square meters of honeycomb panel.
As an experienced professional manufacturer of exterior curtain wall building and decoration materials, RENOXBELL has the unique advantages: Besides RENOXBELL has engaged in the designing, manufacturing and selling of high-class exterior curtain wall building and decoration materials more than 10 years, also we own more than 10 R & D specialists who have been undertaking this industry more than 10 years, some of them even has 15 years experience; The most advanced lamination production line imported from Germany and Italy, which is fully automatic, and numerically controlled.
Over the past 10 years, quality always has been our high priority. Based on this concept, we insist on using the most advanced production equipments, choosing the best materials, such as USA PPG and Sweden Berger fluorocarbon coating, AA3003 and AA5005 high quality aluminum alloy foil, fire-proof PE core materials, and American DuPont or Japanese MITSUBISHI Macromolecule sticking film. We have adopted TUV ISO: 9001: 2000 as our quality control systems. We have our product tested and they are all qualified, and get CE, TUV, SGS certificates and also have passed the test of ASTM.
Our Product has been chosen by many worldwide organizations, such as France DECATHLON, Dubai Bus Station, American PRD Corporation, Russian Petroleum Building, Japanese Hokkaido Bus Station and Guangzhou Baiyun New Airport, etc., and has received extensive recognition.
