Raw Material
ZJGLEADER MGO Board uses proprietary processes with MgO, MgCl2, Perlite, Fiberglass, Chip compounds to deliver a multi-purpose,versatile,non-combustible,and unique board material.
Specification
Edge: square, taper, beveled, grooved and tongue
Standard size : 900*2700mm/915*2750mm
1200*2300mm/1220*2440mm
1200*2500mm/1220*2500mm
1200*3000mm/1220*3000mm
Max width : 1220mm
Max length : 3000mm
Thickness range : 3mm-20mm
Available color : white,black,red,pink,green,blue and grey
Special size are available according to your demands.
Data Information
Heading | Unit Used | Inspection value | Standard |
Density | g/cm³ | 0.96-1.12g/cm³ | GB 8624 |
Fire ratings | grade | A1 | GB/T7019-1997 |
Thermal Resistance | m²K/W | 1.14m²K/w | GB/T13475-92 |
Bending Resistance(Dry) | ≤Mpa | 18Mpa | GB/T7019-1997 |
Bending Resistance(Fully Absorbed in Water) | ≤Mpa | 22Mpa | GB/T7019-1997 |
Sound Insulation | dB | ≥44dB | GBJ121-88 |
Absorption Moisture | ≤% | ≤15% | GB/T7019-1997 |
Tensile Strength | ≤Mpa | 8-13Mpa | GB/T7019-1997 |
Impact Resistance | kj/m² | Between 2.0-2.5 are qualified, for 4mm,our board could reach 4.5kj/m² so our boards are good. | CNS 13778 |
Main Features
1.Fireproof :
Magnesium fireproof board was tested by the National Center for Quality Supervision and Testing of Fire Building Materials (NFTC). Its fireproof level is rated level A (nonflammable level).
2.Moisture-resistance:
Magnesium fireproof board is excellent in moisture-resistance. Dry bending strength is 15MPa. Bending strength under absorbed moisture is 22MPa.
3.Heat insulation:
Magnesium fireproof board has heat prevention material incorporated, it has great feature of heat prevention. Thermal resistance is 1.14m, 2kW.
4.Sound insulation:
Magnesium fireproof board is proved to have good noise insulation property after inspected by the National Center for Quality Supervision and Testing of Fire Building Materials (NFTC), the noise insulation factor of the wall can reach 44dB and 47dB. It has the best noise insulation constitution in China,especially the 95mm wall comprised by the 10mm board.
5.Bump-resistance and light:
Magnesium fireproof board is a light board. Its density is less than 1.0 g/cm3. At the same time its bending strength and impact resistance is excellent. Also, it will maintain its' quality during construction. It is light, that can save time, space, weight and expense.It is a new and high efficient wall board.
6.Popular in all over the world:
Because of the large output and the high technology using in producing the board, the price of the magnesium fireproof board is competitive in the oversea market.
Application
1.roof partition
2.room partition
3.ceiling design
4.furniture decoration
5.exterior wall decoration
6.interior wall decoration
Why choose ZJGLEADER company?
ZJGLEADER Import and Export CO.Ltd. has a sound quality control system,normative progress operation standard,and advanced production equipment.
ZJGLEADER MGO Board has achived relevant certificates like CE,SGS and ISO9001~2000.All of them were recognized by authorities.
Our excellent product and sincere service will satisfy you if you give us a chance.So,if you have any requirements or problems,please contact me immediately!
Person:Daisy Jiang
Tel:86-512-5672 8112
Fax:86-512-5672 8511
Zhangjiagang Leader Import & Export Co., Ltd. is the key member of Leader Group Industry Co., Ltd., been dedicated to the R&D, manufacture and international trade of fire-proof material, ceiling and wall partition system since 2002. At present, we have our own factories in Zhangjiagang City.
The main products we manufacture and export as below:
A. MGO board
(Common board, Sanded board, Slurry board)
B. Ceiling
(Perforated acoustic panel, PVC ceiling, Mineral fiber ceiling)
C. SIP sandwich panel
(MGO+EPS/XPS+MGO, FCB+EPS/XPS+FCB, FCB+EPS/XPS+MGO)
D. Cladding
(Pattern: Impression, Tile, Face brick, Timber grain, Sand rock, Broken stone, Broken brick, Ceramic brick, ODD brick, Culture stone)
E. Fiber cement board/Calcium silicate board
F. Melamine MGO board
(HPL, UV, Plywood)
G. Stone coated metal roof tile
(Angle hip, Eave flashing, Valley tray, Box barge cover)
H. Accessories
(Screw, Tape, T-grid, Steel stud)
Since 2007, we have invested over $10 million with 6 workshops and 6 automatic production lines in the production of construction materials, annual output is over 20, 000, 000 sqm. " Leader" brand of products are welcomed in Southeast Asia, the US, the Middle East and other countries and regions.
We produce your orders following ISO 9001: 2008 and CIS management guidelines. We constantly insist on the principle-quality and customers first that no substandard products can be delivered to clients.
