Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB,CIF,EXW |
Min Order: | 1/Piece |
Pay Type: | T/T,Paypal,Money Gram,Western Union |
Prod Model: | FNS-C10374L2S-L |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
VPN Support: | Yes |
Type: | Wired |
Application: | SOHO |
Transfer Rate: | 10/100/1000Mbps |
Ports: | 6 |
Model NO. |
FNS-C10374L2S-L |
CPU |
Integrated Intel® Celeron 1037U Dual-core 1.8GHz TDP 17W |
Chipset |
Intel® NM70 Express Chipset |
Memory |
Dual-channel SO DDR3 1333/1066 memory slot, Max. up to 16GB |
Display port |
1* DB15 VGA port |
Network Function |
Integrated 4* Intel 82574L 10/100/1000Mbps Ethernet |
|
Integrated 2* Intel NH82580EB Gigabit Optical fiber |
|
Supporting Wake-on-LAN and PXE function |
|
Support 2 groups of BYPASS function |
Wireless Network |
Providing 1* Mini-PCIE slot, support WIFI/3G module |
Storage |
Providing a 3.5/2.5inch SATA disk location |
|
1* MSATA slot, support SSD 6Gbps |
|
1* CF card slot |
Panel Port |
1* COM(CISCO Standard Interface) |
|
2* USB 2.0 port |
|
6* LAN port |
|
2* Fiber socket |
|
1* POWER Switch |
|
1* POWER_LED, HDD_LED Indicator |
|
2* SFPLED |
|
1* VGA port (Rear panel) |
Cooling system |
1* CPUFNA, 2* SYSFAN |
Operating Temp. |
-0°C~50°C |
Storage Temp. |
-20°C~70°C |
Humidity |
5%-95% (relative humidity; non-condensing) |
Anti vibration |
5~300Hz/random operating |
Power |
AC to DC_12V power supply 10A |
Installation |
1U chassis frame |
Material and Process |
Surface sandblasting oxidation process (Silver gray) |
Size |
430mm(L)* 280mm(W)* 46.2mm(H) |
